| 1. |
700114185
|
[1] |
CRANK
|
CAS
BELLCRANK WA - left
|
| 2. |
219-93
|
[3] |
LUBE NIPPLE,90 Degree Elbow, 1/4" - 28 NPTF
|
CAS
Superseded by part number: 87415
|
| 3. |
63677
|
[3] |
WASHER
|
IH
1/2 X 1-27/64 CLEVIS PIN Superseded by part number: 2975160, 2975160, IH63677
|
| 4. |
700114196
|
[2] |
STEM
|
IH
ROD
|
| 5. |
425-108
|
[8] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 6. |
66183
|
[4] |
SHAFT
|
NNA
Superseded by part number: 066183
|
| 7. |
700114177
|
[1] |
TUBE ASSY.
|
HFI
TUBE - pickup torque
|
| 8. |
63966
|
[1] |
PIN
|
CAS
1/2 X 2 CLEVIS PIN
|
| 9. |
700114190
|
[1] |
CLEVIS
|
HFI
WA
|
| 10. |
705541
|
[1] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 11. |
700707873
|
[1] |
THRUST BEARING
|
IH
BEARING - thrust Superseded by part number: 700722820
|
| 12. |
6292387
|
[1] |
SPACER,31.75 mm OD, 44.5 mm Length
|
CAS
TUBE
|
| 13. |
700114197
|
[1] |
TUBE,21 mm ID, 25.4 mm OD, 72 mm Length
|
CAS
- crank
|
| 14. |
9406829
|
[1] |
HEX SOC SCREW,1/2" - 13 x 3 1/2"
|
IH
1/2-13 X 3-1/2 HSHCS SPL
|
| 15. |
700114193
|
[1] |
CRANK
|
CAS
WA
|
| 16. |
702019
|
[1] |
SCREW
|
CAS
3/8-16 X 4 HSHCS SPL Superseded by part number: 61-33864
|
| 17. |
492-11038
|
[1] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 18. |
425-106
|
[1] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 19. |
700114183
|
[1] |
LEVER
|
CAS
WA
|
| 20. |
6869382
|
[1] |
SPACER
|
HFI
|
| 21. |
432-1020
|
[4] |
COTTER PIN,5/32" x 1 1/4"
|
CAS
PIN, SPLIT (COTTER), 5/32" x 1 1/4" Superseded by part number: 86523851
|
| 22. |
432-1624
|
[2] |
COTTER PIN,1/4" x 1 1/2"
|
CAS
Pin, Split (Cotter), 1/4" x 1-1/2" Superseded by part number: 80753
|
| 23. |
52258
|
[2] |
BUSHING
|
CAS
1 X 14 GAUGE NRMB
|
| 24. |
413-820
|
[2] |
BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 72187215, 87670
|
| 25. |
495-21056
|
[2] |
WASHER,1/2"
|
CAS
1/2 WIDE PLAIN WASHER Superseded by part number: 72187265, 80700
|
| 26. |
80679
|
[2] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 27. |
700114186
|
[1] |
CRANK
|
CAS
BELLCRANK WA - right
|
| 28. |
51200240
|
[2] |
BUSHING
|
CAS
|
