神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE - K909LC & MD240BLC (1/87-12/06) (03-019) - FUEL FILTER P/N ME035396 Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
321 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-6. | VAME035396 | [1] | FUEL FILTER | KOB Superseded by part number: 77269152, VAME072903 |
| 1. | VAME035672 | [1] | CYLINDER HEAD | KOB Superseded by part number: VAME307274 |
| 2. | VAMH035166 | [4] | GASKET | KOBGASKET 14 Superseded by part number: 133378A1 |
| 3. | VAMH037087 | [2] | BOLT | KOBBOLT, CONNECTOR |
| 4. | VAMH037084 | [1] | GLOW PLUG | KOBPLUG, AIR Superseded by part number: 77270641, VAME016894 |
| 5. | VAMH035164 | [1] | GASKET | KOBGASKET 8 Superseded by part number: 133379A1 |
| 6. | VAME035393 | [1] | ELEMENT | KOB Superseded by part number: 47500495 |
| 10. | VAMF140260 | [2] | BOLT | KOBBOLT, FLANGE, 10 X 25 |
| 11. | VAME070247 | [1] | BRACKET, FUEL FILTER, M0 ONLY | |
| . . | VAME070922 | [1] | BRACKET, FUEL FILTER, M3 ONLY | |
| 11A. | VAME070923 | [1] | BRACKET, M3 ONLY | |
| 12. | VAMF140240 | [4] | BOLT | KOBBOLT, FLANGE, 8 X 75, M0 ONLY |
| . . | VAMF140226 | [2] | SCREW | KOBBOLT, FLANGE, 8 X 22, M3 ONLY |
| 13. | VAME920038 | [2] | SPACER, L=46, M0 ONLY | |
| 14. | VAME920039 | [2] | SPACER, L=12, M0 ONLY | |
