现代零件查询R140W-7 REAR AXLE WHEEL HUB(-#0559)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
795 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
REAR AXLE
|
|
| 1. |
ZTAM-00113
|
[2] |
CASE-AXLE
|
|
| 2. |
ZTAM-00044
|
[32] |
BOLT
|
|
| 4. |
ZTAM-00006
|
[4] |
PLUG
|
|
| 5. |
ZTAM-00570
|
[2] |
PLUG-MAGNET
|
|
| 6. |
ZTAM-00064
|
[2] |
SEAL
|
|
| 7. |
ZTAM-00114
|
[2] |
SHAFT-HALF
|
|
| 8. |
ZTAM-00066
|
[16] |
STUD-WHEEL
|
|
| 9. |
ZTAM-00067
|
[2] |
HUB-WHEEL
|
|
| 10. |
ZTAM-00068
|
[2] |
O-RING
|
|
| 11. |
ZTAM-00065
|
[4] |
BEARING
|
|
| K12. |
ZTAM-00079
|
[2] |
CIRCLIP
|
|
| K13. |
ZTAM-00069
|
[2] |
GEAR-RING
|
|
| K14. |
ZTAM-00070
|
[2] |
SUPPORT
|
|
| 15. |
ZTAM-00082
|
[2] |
PLATE-LOCKING
|
|
| K16. |
ZTAM-00071
|
[8] |
CIRCLIP
|
|
| K17. |
ZTAM-00072
|
[8] |
GEAR-PLANET
|
|
| K18. |
ZTAM-00073
|
[8] |
BEARING
|
|
| 19. |
ZTAM-00074
|
[20] |
NUT
|
|
| 20. |
ZTAM-00115
|
[2] |
SEAL
|
|
| 22. |
ZTAM-00075
|
[4] |
BOLT-COUNTERSUNK
|
|
| K23. |
ZTAM-00579
|
[2] |
CARRIER-PLANET GEAR
|
|
| 24. |
ZTAM-00078
|
[16] |
NUT
|
|
| 25. |
ZTAM-00077
|
[16] |
STUD
|
|
| 26. |
ZTAM-00116
|
[2] |
WASHER-FRICTION
|
|
| 29. |
ZTAM-00083
|
[4] |
STUD-WHEEL
|
|
| K. |
ZTAM-00583
|
[2] |
CARRIER KIT
|
|
