纽荷兰零件查询(F4HFE613F A001) - ENGINE 5801753674 - 47541731 (1/14-) (10.210.AF) - FUEL LINE New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
294 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4895483 | [12] | BOLT,Flng, M6 x 1 x 35mm | TORM6 x 1 x 35 |
| 2. | 2854606 | [6] | FUEL TUBE,Connector Assembly | SMASSY, Incl 3, 4 |
| 3. | 4890929 | [1] | O-RING,3mm Thk x 11mm ID | TORID = 11.0 x 3.0 |
| 4. | NSS | [1] | NOT SERVICED SEPARATELY | CONFitting, Incl in 2 |
| 5. | 2855135 | [6] | FUEL SYSTEM INJECTOR | TORASSY, Incl 6 - 9 Superseded by part number: 504128307 |
| 5. | 2855135R | [6] | REMAN-FUEL INJECTOR | RACReman For New PN 2855135 |
| 5. | 2855135C | [6] | CORE-FUEL INJECTOR | RACReturn Number |
| 6. | 2854609 | [1] | BRACKET | TOR Superseded by part number: 504091492 |
| 7. | 4890926 | [1] | O-RING,3mm Thk x 20.9mm ID, 60 Duro | TORID = 20.9 x 3.0 |
| 8. | 4899689 | [1] | SEALING WASHER,7mm ID x 15mm OD x 1.5mm Thk | TOR |
| 10. | 4893739 | [6] | TUBE NUT | TOR |
