现代零件查询R140W-7 TRANSMISSION INPUT GROUP(-#0559)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
410 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
TRANSMISSION
|
|
| 020. |
ZGAQ-00935
|
[2] |
RING-PISTON
|
|
| 030. |
ZGAQ-00936
|
[1] |
GASKET
|
|
| 040. |
ZGAQ-00937
|
[1] |
O-RING
|
|
| 050. |
ZGAQ-00938
|
[1] |
V-RING
|
|
| 060. |
ZGAQ-00939
|
[1] |
BEARING-BALL
|
|
| 110. |
ZGAQ-00940
|
[1] |
V-RING
|
|
| 130. |
ZGAQ-00941
|
[1] |
VALVE-THROTTLE
|
|
| 160. |
ZGAQ-00942
|
[1] |
BUSHING-GUIDE
|
|
| 170. |
ZGAQ-00943
|
[2] |
O-RING
|
|
| 180. |
ZGAQ-00944
|
[1] |
SEAL-SHAFT
|
|
| 190. |
ZGAQ-00945
|
[1] |
RING-SNAP
|
|
| 200. |
ZGAQ-00946
|
[1] |
RETAINER RING
|
|
| 210. |
ZGAQ-00947
|
[1] |
SHAFT-INPUT
|
|
