神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE FOR K904C, K907B, K907C & YS750-2 (1/77-12/06) (01-008) - CONNECTING ROD & BEARING Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
524 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-5. | VAME032546 | [6] | LINK CONROD | KOBCONNECTING ROD ASSY Superseded by part number: 77269089, VAME072119 |
| 1. | NSS | [6] | NOT SOLD SEPARAT | CONROD, CONNECTING |
| 2. | NSS | [6] | NOT SOLD SEPARAT | CONCAP, CONN-ROD |
| 3. | VAME032553 | [12] | SCREW | KOBBOLT |
| 4. | VAME032042 | [12] | NUT | KOBNUT Superseded by part number: 132467A1 |
| 5. | VAME032014 | [6] | BUSHING BUSHING, CONN-ROD | BUSHING BUSHING, CONN-ROD |
| 6. | VAME032518 | [1] | SET OF STD MAIN BRGS | KOBCONNECTING ROD BEARING SET, SET Superseded by part number: VAME997367 |
| 6. | VAME032519 | [1] | BEARING LINER | KOBCONNECTING ROD BEARING SET, US 0.25 Superseded by part number: VAME997368 |
| 6. | VAME032520 | [1] | BEARING LINER | KOBCONNECTING ROD BEARING SET, US 0.50 Superseded by part number: VAME999896 |
| 6. | VAME032521 | [1] | BEARING LINER | KOBCONNECTING ROD BEARING SET, US 0.75 |
| 6. | VAME032522 | [1] | BEARING LINER | KOBCONNECTING ROD BEARING SET, US 1.00 |
