凯斯零件查询(8465) - CASE IH AUTO ROUND BALER (1/91-12/97) (8-24) - HYDRAULIC CYLINDER ASSY., TENSIONER & EJECTOR, 700712161 HYD. CYL. COMPLETE, 2" BORE X 12 " STROKE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
905 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700712161
|
[1] |
CYLINDER ASSY.,Double Acting, 38.1mm Rod, 304.8mm Stroke
|
IH
HYDRAULIC CYLINDER COMPLETE (2 inch bore x 12 inch stroke)
|
| 1. |
700711112
|
[1] |
GUIDE
|
CAS
|
| 2. |
700707421
|
[1] |
ROD
|
CAS
|
| 3. |
700707418
|
[1] |
JAM NUT
|
CAS
7/8-14 HEX JAM NUT
|
| 4. |
700707419
|
[1] |
PISTON
|
CAS
|
| 5. |
700711114
|
[1] |
SEAL KIT
|
L
SEAL KIT
|
