现代零件查询R140W-7 REAR AXLE BRAKE DISC(#0560-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
345 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
REAR AXLE
|
|
| 1. |
ZTAM-00090
|
[8] |
DISC-BRAKE
|
|
| 2. |
ZTAM-00617
|
[6] |
BOLT-ADJUSTING
|
|
| K3. |
ZTAM-00092
|
[6] |
SPRING
|
|
| K4. |
ZTAM-00093
|
[2] |
PISTON
|
|
| 5. |
ZTAM-00094
|
[6] |
SPRING
|
|
| K6. |
ZTAM-01202
|
[2] |
O-RING
|
|
| K7. |
ZTAM-01202
|
[2] |
O-RING
|
|
| K8. |
ZTAM-01201
|
[2] |
O-RING
|
|
| K9. |
ZTAM-01201
|
[2] |
O-RING
|
|
| 10. |
ZTAM-00099
|
[10] |
BRAKE DISC-INTERMEDIATE
|
|
| 11. |
ZTAM-00100
|
[2] |
BOLT-BLEEDING
|
|
| 12. |
ZTAM-00101
|
[2] |
PLUG
|
|
| 13. |
ZTAM-00618
|
[2] |
BOLT-PILOT
|
|
| K. |
ZTAM-00591
|
[2] |
PISTON KIT
|
|
