| 1. |
413-616
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 2. |
492-11038
|
[8] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 3. |
425-106
|
[10] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 4. |
296608
|
[2] |
BOLT,3/8" - 16 x 2"
|
CAS
- eye
|
| 5. |
700125909
|
[1] |
SUPPORT
|
HFI
WA - left
|
| 6. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, , straight, taper 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 7. |
121-226
|
[4] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 8. |
232-5316
|
[4] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 9. |
700124565
|
[1] |
SHAFT
|
HFI
WA
|
| 10. |
432-816
|
[1] |
COTTER PIN,1/8" x 1"
|
CAS
1/8" x 1" Superseded by part number: 80755
|
| 11. |
496-11041
|
[2] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 12. |
434-412
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, 1/4" - 20 x 3/4", Gr 5
|
CAS
1/4-20 X 3/4 RHSNB Superseded by part number: 280638
|
| 13. |
1703354
|
[4] |
NUT
|
IH
1/4-20 HFTLN GR/G
|
| 14. |
700119161
|
[1] |
SWITCH
|
L
ASSEMBLY
|
| 15. |
700125910
|
[1] |
MOUNTING PARTS
|
HFI
MOUNT - switch
|
| 16. |
751321
|
[1] |
CLAMP
|
CAS
- line Superseded by part number: 80272535
|
| 17. |
413-436
|
[1] |
BOLT,Hex, 1/4" - 20 x 2-1/4", Gr 5
|
CAS
Superseded by part number: 87405
|
| 18. |
231-5144
|
[1] |
SERRATED NUT,Flg, USR, 1/4"-20
|
CAS
Superseded by part number: 523282, 72187066
|
| 19. |
700124563
|
[1] |
MOUNTING PARTS
|
HFI
MOUNTING WA
|
| 20. |
20948R1
|
[1] |
PIN,1/8" x 5/8", Coiled
|
IH
|
| 21. |
700710211
|
[1] |
ACTUATOR
|
IH
|
| 22. |
496-81010
|
[7] |
WASHER
|
CAS
3/8 HARDENED WIDE PLAIN WASHER Superseded by part number: 86625244
|
| 23. |
433-512
|
[6] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 24. |
230-4115
|
[6] |
LOCK NUT,5/16"-18, GA
|
CAS
5/16-18 HTLN GR/B Superseded by part number: 230-4145
|
| 25. |
700125720
|
[2] |
PLATE
|
HFI
|
| 26. |
50567
|
[4] |
RATCHET
|
NNA
Superseded by part number: 51200380, 51200380, NLS
|
| 27. |
50302
|
[2] |
SPHERICAL BEARING,25.4 mm ID x 52 mm OD x 30.96 mm
|
CAS
Superseded by part number: 204807C91, 47577183
|
| 28. |
700125828
|
[1] |
SUPPORT
|
HFI
WA - brake
|
| 29. |
413-652
|
[1] |
BOLT,Hex, 3/8" - 16 x 3-1/4", Gr 5
|
CAS
Superseded by part number: 9637240
|
| 30. |
231-4116
|
[1] |
NUT,3/8"-16, GB
|
CAS
3/8-16 HTLN GR/B Superseded by part number: 88902, E64197
|
| 31. |
440-12512
|
[2] |
SCREW,Cross Pan Hd, 1/4"-20 x 3/4"
|
CAS
GR 2 Cross Pan Hd, 1/4"-20 x 3/4" Superseded by part number: 86511932
|
| 32. |
413-644
|
[1] |
BOLT,Hex, 3/8" - 16 x 2-3/4", Gr 5
|
CAS
C Hex, 3/8"-16 x 2 3/4", G5 Superseded by part number: 88444
|
| 33. |
700710930
|
[1] |
PAD
|
CAS
- brake
|
| 34. |
58107
|
[1] |
SPRING
|
IH
- compression
|
| 35. |
700109003
|
[1] |
BUSHING
|
CAS
|
| 36. |
T13450
|
[2] |
KEY
|
CAS
1/4 X 1-1/4 KEY
|
| 37. |
700125721
|
[1] |
SUPPORT
|
HFI
WA - right
|
| 38. |
7758915
|
[1] |
SPRING
|
CAS
- extension
|
| 39. |
434-616
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 40. |
111-361
|
[2] |
CARRIAGE BOLT,Short NK, 3/8"-16 x 1 1/2", G5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/2", G5 Superseded by part number: 9706752
|
