卡特零件查询（725） 148-9972: LINES GP-SERVICE BRAKE
广数供应链运营团队, 14 02月, 2025，浏览：
860 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 5P-8867 | [4] | INSERT-FLARED | |
| 2. | 7U-9277 | [2] | MANIFOLD | |
| 3. | 148-8340 | [2] | CONNECTOR AS | |
| | | | (EACH INCLUDES) |
| | 6V-8639 | [1] | CONNECTOR | |
| | 6V-8398 | [1] | SEAL-O-RING | |
| | 3K-0360 | [1] | SEAL-O-RING | |
| 4. | 148-8454 | [1] | TEE AS | |
| | 6V-8789 | [1] | TEE | |
| | 6V-8398 | [3] | SEAL-O-RING | |
| 5. | 176-5689 | [2] | TUBE AS | |
| 6. | 176-5690 | [1] | TUBE AS | |
| 7. | 176-8111 | [1] | TUBE AS | |
| 8. | 189-3068 | [1] | TUBE AS | |
| 9. | 189-3069 | [1] | TUBE AS | |
| 10. | 8T-1885 | [3] | CLIP(SLOT) | |
| 11. | 8T-1886 | [3] | CLIP(TAB) | |
| 12. | 8T-4121 | [2] | WASHER-HARD(11X21X2.5-MM THK) | |
| 13. | 8T-4137M | [2] | BOLT(M10X1.5X20-MM) | |
| 14. | 8T-4189M | [1] | BOLT(M8X1.25X20-MM) | |
| 15. | 8T-4197M | [2] | BOLT(M8X1.25X40-MM) | |
| 16. | 8T-4224 | [5] | WASHER-HARD(8.8X16X2-MM THK) | |
| | M | | METRIC PART |
