神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE FOR K904C, K907B, K907C & YS750-2 (1/77-12/06) (02-006) - FAN & PULLEY (ME039960) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
292 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME039960 | [1] | FAN | KOBFAN,SUCTION TYPE PPG D=600 |
| 2. | VAME039962 | [1] | SPACER | KOBSPACER,FAN L=30, (FOR M0,M1&M7) |
| 2. | VAME039964 | [1] | SPACER SPACER,FAN L=50, (FOR M2,M3,M5&M6) | SPACER SPACER,FAN L=50, (FOR M2,M3,M5&M6) |
| 2. | VAME039965 | [1] | SPACER SPACER,FAN L=65 (FOR M4 ONLY) | SPACER SPACER,FAN L=65 (FOR M4 ONLY) |
| 4. | VAMF300853 | [4] | BOLT | KOBBOLT,W/W5R 10x60 (FOR M0,M1&M7) Superseded by part number: VAF200510060 |
| 4. | VAMF300857 | [4] | BOLT | KOBBOLT, W/WSR 10x80 (FOR M2,M3,M5&M6) |
| 4. | VAMH000194 | [4] | BOLT | KOBBOLT,W/WSR 10x95 (FOR M4 ONLY) |
| 6. | VAME020731 | [1] | PLATE | KOBPLATE,WSR |
| 7. | VAME035061 | [1] | BELT, TRANSMISSION | KOBV-BELT,2 BELTS SET B L=1050 (FOR M0,M3) Superseded by part number: VAME902741 |
| 7. | VAME902741 | [1] | BELT, TRANSMISSION | KOBV-BELT,B L=1065 (FOR M1,M2,M4,M5) |
| 7. | VAME902740 | [1] | BELT, TRANSMISSION | KOBV-BELT,B L=1040 (FOR M6&M7 ONLY) |
| 8. | VAME900240 | [1] | BELT, TRANSMISSION | KOBV-BELT A L=1046 (FOR M5 ONLY) |
| . . | VAME900239 | [1] | BELT | KOBA L=L021 (FOR M6 ONLY) |
