现代零件查询R140W-7 SWING REDUCTION GEAR(#0057-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
690 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
SWING MOTOR ASSY
|
|
| . |
@
|
[1] |
SWING MOTOR ASSY
|
|
| -2. |
31N4-10140
|
[1] |
SWING REDUCTION GEAR
|
|
| -2. |
31N4-10141
|
[1] |
SWING REDUCTION GEAR
|
|
| 1. |
XKAQ-00134
|
[1] |
CASING
|
|
| 1. |
XKAQ-00332
|
[1] |
CASING
|
|
| 2. |
XKAQ-00249
|
[1] |
SHAFT-DRIVE
|
|
| 3. |
XKAQ-00102
|
[1] |
GEAR-RING
|
|
| 5. |
XKAQ-00278
|
[1] |
GEAR-SUN NO.2
|
|
| -21. |
XKAQ-00271
|
[1] |
CARRIER NO.1 ASSY
|
|
| 6. |
XKAQ-00099
|
[3] |
GEAR-PLANET NO.1
|
|
| 7. |
XKAQ-00277
|
[1] |
GEAR-SUN NO.1
|
|
| 9. |
XKAQ-00096
|
[1] |
CARRIER NO.1
|
|
| 11. |
XKAQ-00094
|
[3] |
PIN ASSY NO.1
|
|
| 12. |
XKAQ-00093
|
[6] |
WASHER-THRUST(B)
|
|
| 13. |
XKAQ-00057
|
[1] |
PLATE-SIDE 1
|
|
| 23. |
XKAQ-00086
|
[3] |
PIN-SPRING
|
|
| 24. |
XKAQ-00085
|
[4] |
RING-STOP
|
|
| 29. |
XKAQ-00080
|
[3] |
CAGE-NEEDLE
|
|
| -22. |
XKAQ-00272
|
[1] |
CARRIER NO.2 ASSY
|
|
| 4. |
XKAQ-00101
|
[4] |
GEAR-PLANET NO.2
|
|
| 8. |
XKAQ-00097
|
[1] |
CARRIER NO.2
|
|
| 10. |
XKAQ-00095
|
[4] |
PIN ASSY NO.2
|
|
| 12. |
XKAQ-00093
|
[4] |
WASHER-THRUST(B)
|
|
| 23. |
XKAQ-00086
|
[4] |
PIN-SPRING
|
|
| 16. |
XKAQ-00091
|
[2] |
PIN-KNOCK
|
|
| 17. |
XKAQ-00090
|
[1] |
BEARING-SPH ROLLER
|
|
| 18. |
XKAQ-00089
|
[1] |
BEARING-CYL ROLLER
|
|
| 19. |
XKAQ-00088
|
[10] |
BOLT-SOCKET
|
|
| 20. |
XKAQ-00087
|
[1] |
SEAL-OIL
|
|
| 21. |
XKAQ-00049
|
[1] |
PLUG
|
|
| 22. |
XKAQ-00066
|
[2] |
PLUG
|
|
| 25. |
XKAQ-00084
|
[1] |
RING-STOP
|
|
| 26. |
XKAQ-00083
|
[1] |
SPACER
|
|
| 27. |
XKAQ-00082
|
[1] |
PLATE-COVER
|
|
| 28. |
XKAQ-00081
|
[6] |
BOLT-HEX
|
|
| 31. |
XKAQ-00333
|
[4] |
CAP-RUBBER
|
|
