现代零件查询R140W-7 TRAVEL MOTOR(1/2, #0131-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
579 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31N4-45011
|
[1] |
TRAVEL MOTOR
|
|
| . |
31N4-45012
|
[1] |
TRAVEL MOTOR
|
|
| 1. |
XJDD-00336
|
[1] |
ROTARY GROUP
|
|
| 1-1. |
XJDD-00337
|
[1] |
ROTARY-HYD SECTION
|
|
| 1-1-1. |
XJDD-00230
|
[1] |
CYLINDER
|
|
| 1-1-2. |
XJDD-00231
|
[1] |
CONTROL LENS
|
|
| 1-1-3. |
XJDD-00232
|
[1] |
PIN-CENTER
|
|
| 1-1-4. |
XJDD-00233
|
[7] |
PISTON ASSY
|
|
| 1-1-6. |
XJDD-00234
|
[1] |
SHIM(3.5T)-ADJUST
|
|
| 1-1-6. |
XJDD-00235
|
[1] |
SHIM(3.6T)-ADJUST
|
|
| 1-1-6. |
XJDD-00236
|
[1] |
SHIM(3.7T)-ADJUST
|
|
| 1-1-6. |
XJDD-00237
|
[1] |
SHIM(3.8T)-ADJUST
|
|
| 1-1-6. |
XJDD-00238
|
[1] |
SHIM(3.9T)-ADJUST
|
|
| 1-1-6. |
XJDD-00239
|
[1] |
SHIM(4.0T)-ADJUST
|
|
| 1-1-7. |
XJDD-00240
|
[1] |
SPRING-PRESSURE
|
|
| 1-1-11. |
XJDD-00241
|
[1] |
PLATE-RETAINING
|
|
| 1-1-12. |
XJDD-00674
|
[14] |
SCREW-PAN HEAD
|
|
| 1-2. |
XJDD-00216
|
[1] |
SHAFT-DRIVE
|
|
| 1-3. |
XJDD-00217
|
[1] |
SHIM(5.9T)
|
|
| 1-6. |
XJDD-00218
|
[1] |
PLATE(3.1T)-BACK UP
|
|
| 1-6. |
XJDD-00219
|
[1] |
PLATE(3.5T)-BACK UP
|
|
| 1-6. |
XJDD-00220
|
[1] |
PLATE(3.45T)-BACK UP
|
|
| 1-6. |
XJDD-00221
|
[1] |
PLATE(3.4T)-BACK UP
|
|
| 1-6. |
XJDD-00222
|
[1] |
PLATE(3.35T)-BACK UP
|
|
| 1-6. |
XJDD-00223
|
[1] |
PLATE(3.3T)-BACK UP
|
|
| 1-6. |
XJDD-00224
|
[1] |
PLATE(3.25T)-BACK UP
|
|
| 1-6. |
XJDD-00225
|
[1] |
PLATE(3.2T)-BACK UP
|
|
| 1-6. |
XJDD-00226
|
[1] |
PLATE(3.15T)-BACK UP
|
|
| 1-7. |
XJDD-00227
|
[1] |
RING-RETAINING
|
|
| 1-10. |
XJDD-00228
|
[1] |
BEARING-ROLLER
|
|
| 1-11. |
XJDD-00229
|
[1] |
BEARING-ROLLER
|
|
| 5. |
XJDD-00209
|
[1] |
HOUSING
|
|
| 8. |
XJDD-00210
|
[1] |
SCREW-LOCKING
|
|
| 9. |
XJDD-00211
|
[1] |
RING-RETAINING
|
|
| K10. |
XJDD-00212
|
[1] |
SEAL RING-SHAFT
|
|
| 11. |
XJDD-00213
|
[1] |
PLATE-BACK UP
|
|
| K12. |
XJDD-00214
|
[1] |
O-RING
|
|
| 13. |
XJDD-00210
|
[1] |
SCREW-LOCKING
|
|
| 17. |
XJDD-00211
|
[2] |
RING-RETAINING
|
|
| K18. |
XJDD-00120
|
[2] |
NUT-SEAL LOCK
|
|
| -1. |
@
|
[1] |
CONTROL PART
|
|
| -2. |
@
|
[1] |
COUNTER BALANCE VALVE
|
|
| K. |
XJDD-00683
|
[1] |
SEAL KIT
|
|
