现代零件查询R140W-7 DOZER BLADE CYLINDER-FRONTEPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
647 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
35EA-70350
|
[1] |
DOZER BLADE CYLINDER
|
|
| N . |
35EA-70360
|
[1] |
DOZER BLADE CYLINDER
|
|
| -1. |
31Y1-18661
|
[1] |
BLADE CYL SUB ASSY
|
|
| 1. |
31Y1-18671
|
[1] |
TUBE ASSY
|
|
| 2. |
31Y1-18000
|
[1] |
ROD ASSY
|
|
| 3. |
31Y1-17500
|
[1] |
GLAND
|
|
| 4. |
S732-065030
|
[1] |
BUSHING-DD2
|
|
| K5. |
Y220-065011
|
[1] |
SEAL-ROD,IUH
|
|
| K6. |
Y180-065020
|
[1] |
RING-BACK UP
|
|
| K7. |
Y240-065011
|
[1] |
RING-BUFFER
|
|
| K8. |
Y110-065011
|
[1] |
WIPER-DUST,DKBI,DLW
|
|
| 9. |
Y190-079000
|
[1] |
RING-SNAP
|
|
| K10. |
S632-100001
|
[1] |
O-RING
|
|
| K11. |
S632-095004
|
[1] |
O-RING
|
|
| K12. |
S642-095003
|
[1] |
RING-BACK UP
|
|
| 13. |
31Y1-10460
|
[1] |
PISTON
|
|
| K14. |
31YC-99370
|
[1] |
O-RING
|
|
| K15. |
31YC-99390
|
[2] |
RING-BACK UP
|
|
| K16. |
Y420-100000
|
[1] |
SEAL-PISTON
|
|
| K17. |
Y300-100000
|
[1] |
RING-WEAR
|
|
| K18. |
Y440-100000
|
[1] |
RING-DUST
|
|
| 19. |
31YC-65340
|
[1] |
NUT-NYLON
|
|
| 20. |
31Y1-18700
|
[1] |
PIPE ASSY-LH
|
|
| 20. |
31Y1-18710
|
[1] |
PIPE ASSY-RH
|
|
| 21. |
35EA-70320
|
[1] |
CHECK VALVE-DOUBLE
|
|
| 21. |
31N4-75020
|
[1] |
CHECK VALVE-DOUBLE,RH
|
|
| 21. |
35EA-70310
|
[1] |
CHECK VALVE-DOUBLE
|
|
| 21. |
31N4-75010
|
[1] |
CHECK VALVE-DOUBLE,LH
|
|
| K22. |
Y171-015004
|
[2] |
O-RING
|
|
| K23. |
S631-014004
|
[1] |
O-RING
|
|
| 24. |
S107-080404
|
[8] |
BOLT-SOCKET
|
|
| 25. |
S107-100554
|
[4] |
BOLT-SOCKET HEAD
|
|
| 26. |
31YC-12210
|
[2] |
BUSHING-PIN
|
|
| 27. |
Y010-065080
|
[4] |
SEAL-DUST
|
|
| 28. |
S651-810002
|
[1] |
NIPPLE-GREASE
|
|
| K. |
31Y1-17660
|
[1] |
SEAL KIT
|
|
