神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE FOR K904C, K907B, K907C & YS750-2 (1/77-12/06) (06-008) - AIR INTAKE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
695 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VA3003070010 | [1] | AIR CLEANER | KOBAIR CLEANER ASSY SEE FIG 06-010 (FOR M1,M3 ONLY) FF: PARTS |
| 2-4. | VA3003070200 | [1] | AIR PRE-CLEANER ASSY | KOBPRE-CLEANER ASSY (FOR M3 ONLY) FF: PARTS |
| 2. | VAME048211 | [1] | COVER (FOR M3 ONLY) : PARTS | |
| 3. | VAME963901 | [1] | BODY BODY (FOR M3 ONLY): PARTS | BODY BODY (FOR M3 ONLY): PARTS |
| 4. | VAME048210 | [1] | SLEEVE (FOR M3 ONLY) | |
| 5. | VA3003072100 | [1] | CAP | KOBCAP (FOR M1 ONLY) : PARTS Superseded by part number: VAME048569 |
| 10. | VA3003070500 | [2] | BAND BAND,MOUNTING : PARTS | BAND BAND,MOUNTING : PARTS |
| 13. | VA3123011840 | [4] | CLAMP | KOBCLAMP,HOSE Superseded by part number: 134979A1 |
| 14. | VA3003091300 | [1] | HOSE HOSE,RUBBER L=490 (FOR M3 ONLY) : PARTS | HOSE HOSE,RUBBER L=490 (FOR M3 ONLY) : PARTS |
| 14. | VA3183094200 | [1] | HOSE | KOBHOSE,RUBBER L = 330 (FOR M4 ONLY): PARTS |
| 16. | VA3183091100 | [1] | HOSE | KOBHOSE,RUBBER L=300 (FOR M1 ONLY) |
| 17. | VA3003070600 | [1] | PIPE HOSE,RUBBER (FOR M3 ONLY) : PARTS | PIPE HOSE,RUBBER (FOR M3 ONLY) : PARTS |
| 19. | VA3003070700 | [1] | ELBOW HOSE,RUBBER, 90 ELB0W (FOR M1 ONLY) : PARTS | ELBOW HOSE,RUBBER, 90 ELB0W (FOR M1 ONLY) : PARTS |
