现代零件查询R140W-7 STEERING VALVEEPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
425 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
81EK-00010
|
[1] |
STEERING VALVE
|
|
| K1. |
YUBS-00001
|
[1] |
SEAL-DUST
|
|
| N2. |
@
|
[1] |
HSG,SPOOL,SLEEVE
|
|
| 3. |
YUBS-00002
|
[1] |
BALL
|
|
| 4. |
YUBS-00003
|
[1] |
BUSHING-THREAD
|
|
| K5. |
YUBS-00056
|
[1] |
O-RING
|
|
| K6. |
YUBS-00057
|
[1] |
RING-KING
|
|
| 7. |
YUBS-00005
|
[1] |
BEARING ASSY
|
|
| 8. |
YUBS-00006
|
[1] |
RING
|
|
| 9. |
YUBS-00007
|
[1] |
PIN-CROSS
|
|
| 11. |
YUBS-00008
|
[1] |
SHAFT-CARDAN
|
|
| 12. |
YUBS-00058
|
[1] |
SPRING SET
|
|
| K13. |
YUBS-00010
|
[1] |
O-RING
|
|
| 14. |
YUBS-00011
|
[1] |
PLATE-DISTRIBUTOR
|
|
| 15. |
YUBS-00059
|
[1] |
SET-GEAR WHEEL
|
|
| K16. |
YUBS-00013
|
[2] |
O-RING
|
|
| 17. |
YUBS-00014
|
[1] |
COVER-END
|
|
| K18. |
YUBS-00015
|
[7] |
WASHER
|
|
| 20. |
YUBS-00060
|
[1] |
SCREW-PIN
|
|
| 21. |
YUBS-00061
|
[6] |
SCREW
|
|
| 22. |
YUBS-00062
|
[1] |
PLATE-NAME
|
|
| 23. |
YUBS-00037
|
[2] |
SCREW-DRIVE
|
|
| 24. |
YUBS-00063
|
[1] |
RELIEF VALVE ASSY
|
|
| 25. |
YUBS-00064
|
[1] |
SPRING-WIRE
|
|
| 26. |
YUBS-00065
|
[2] |
VLV-SHOCK,COMPLETE
|
|
| 27. |
YUBS-00066
|
[2] |
BALL
|
|
| 29. |
YUBS-00067
|
[2] |
BUSHING-W/PIN
|
|
| K. |
YUBS-00068
|
[1] |
SEAL KIT
|
|
| N. |
@
|
[AR] |
NOT INDIVIDUALLY SUPPLIED
|
|
