现代零件查询R140W-7 BRAKE VALVE(-#0572)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
477 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31N4-30110
|
[1] |
BRAKE VALVE ASSY
|
|
| 1. |
XKAK-00001
|
[1] |
BODY-LOWER
|
|
| 2. |
XKAK-00002
|
[1] |
BODY-UPPER
|
|
| 3. |
XKAK-00021
|
[2] |
SPOOL
|
|
| 4. |
XKAK-00004
|
[1] |
PLUG
|
|
| 5. |
XKAK-00005
|
[1] |
HOLDER
|
|
| 6. |
XKAK-00006
|
[1] |
SPRING-LOWER
|
|
| 7. |
XKAK-00007
|
[1] |
SPRING-UPPER
|
|
| 8. |
XKAK-00022
|
[1] |
SPRING-MAIN
|
|
| 9. |
XKAK-00023
|
[1] |
RETAINER-SPRING
|
|
| 10. |
S631-011004
|
[1] |
O-RING
|
|
| 11. |
XKAK-00035
|
[1] |
O-RING
|
|
| 12. |
XKAK-00034
|
[1] |
SEAL-OIL
|
|
| 13. |
XKAK-00010
|
[1] |
GUIDE
|
|
| 14. |
S602-008004
|
[2] |
RING-RETAINER
|
|
| 15. |
S731-025030
|
[1] |
BUSHING-DU
|
|
| 16. |
XKAK-00024
|
[1] |
PLATE-PEDAL
|
|
| 17. |
XKAK-00012
|
[1] |
PEDAL ASSY
|
|
| 17-1. |
XKAK-00013
|
[1] |
PEDAL
|
|
| 17-2. |
XKAK-00014
|
[1] |
PLATE-LOCK
|
|
| 17-3. |
S017-080202
|
[1] |
BOLT-HEX
|
|
| 17-4. |
S403-080002
|
[1] |
WASHER-PLAIN
|
|
| 18. |
XKAK-00015
|
[1] |
COVER-PEDAL
|
|
| 19. |
XKAK-00025
|
[1] |
LATCH
|
|
| 20. |
XKAK-00016
|
[1] |
BELLOWS
|
|
| 21. |
XKAK-00017
|
[1] |
PIN 1-LOCK
|
|
| 22. |
XKAK-00026
|
[1] |
PIN 2-LOCK
|
|
| 23. |
XKAK-00018
|
[1] |
SPRING 1
|
|
| 24. |
XKAK-00027
|
[1] |
SPRING 2
|
|
| 25. |
S601-012004
|
[2] |
RING-RETAINING
|
|
| 26. |
P560-050002
|
[2] |
E-RING
|
|
| 27. |
S017-080302
|
[2] |
BOLT-HEX
|
|
| 28. |
S207-081002
|
[2] |
NUT-HEX
|
|
| 29. |
S107-080252
|
[2] |
BOLT-SOCKET
|
|
| 30. |
S411-080002
|
[4] |
WASHER-SPRING
|
|
| N31. |
@
|
[7] |
PLUG
|
|
| N34. |
@
|
[1] |
WASHER-PLATE
|
|
| 35. |
S602-026004
|
[1] |
RING-RETAINING
|
|
| N. |
@
|
[AR] |
|
|
