HK50456
|
[1] |
WARNING LIGHT KIT COMPLETE
|
|
| 1. |
L18337
|
[10] |
CABLE TIE,9.95"-12.1" lg
|
CAS
STRAP - tie, 15 inch, nylon Superseded by part number: 529070
|
| 2. |
700707926
|
[1] |
HARNESS
|
CAS
- wire
|
| 3. |
700708036
|
[2] |
SIDE LAMP ASSY
|
IH
LIGHT - flasher Superseded by part number: 130609
|
| 4. |
700711749
|
[4] |
LENS
|
CAS
- light, flasher Superseded by part number: 71193862
|
| 5. |
700706634
|
[1] |
STOP LIGHT
|
IH
LIGHT - stop
|
| 6. |
515-2363
|
[7] |
CLAMP,M6.3, Insul, 3/8" Bolt
|
CAS
- line Superseded by part number: 675162
|
| 7. |
700117560
|
[3] |
ANGLE
|
HFI
- mounting, light
|
| 8. |
700705121
|
[1] |
WIRE
|
HFI
- electric
|
| 9. |
700708074
|
[1] |
ELECTRICAL WIRE
|
HFI
WIRE - electric
|
| 10. |
700708075
|
[1] |
ELECTRICAL WIRE
|
CAS
WIRE - electric
|
| 11. |
515-2295
|
[6] |
CLAMP,3/8", Insul, 5/16" Bolt
|
CAS
Line 3/8", Insul, 5/16" Bolt Superseded by part number: 86637978
|
| 12. |
413-512
|
[5] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
CAS
C Hex, 5/16"-18 x 3/4", G5, Full Thd Superseded by part number: 72187196, 87872
|
| 13. |
187-1036
|
[7] |
SELF-TAP SCREW,Hex Washer, 1/4" - 20 x 1/2"
|
CAS
1/4-20 X 1/2 HWHTCTS Superseded by part number: 281-1478
|
| 14. |
722496
|
[4] |
CLIP
|
HFI
- line
|
| 15. |
413-616
|
[6] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 16. |
231-5145
|
[5] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 17. |
492-11038
|
[6] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 18. |
425-106
|
[6] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
