神钢零件查询(6D15) - MITSUBISHI DIESEL ENGINE FOR K904C, K907B, K907C & YS750-2 (1/77-12/06) (03-003) - INJECTION PUMP (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
801 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-54. | NSS | [1] | NOT SOLD SEPARAT | CONINJECTION PUMP ASSY A TYPE NO 0901004200 (ME039621) (FOR M0 ONLY) |
| 1-2A. | VA1901101850 | [1] | HOUSING,PUMP | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONHOUSING,PUMP |
| 1A. | VA0902210030 | [1] | HYD CONNECTOR | KOBADAPTER |
| 1B. | VA0902410010 | [1] | PLUG | KOBAIR BREATHER ASSY |
| 2. | VA9490430010 | [1] | STUD | |
| 2A. | VA9490431630 | [2] | STUD | |
| 3. | VA0901501820 | [6] | PUMP ELEMENT SUB ASSY (FOR M0,M3 ONLY) | |
| 3. | VA0901502850 | [6] | ELEMENT PUMP ELEMENT SUB ASSY (FOR M2 ONLY) | ELEMENT PUMP ELEMENT SUB ASSY (FOR M2 ONLY) |
| 3. | VA0901502780 | [6] | PUMP ELEMENT SUB ASSY (FOR M4 ONLY) | |
| 3. | VA0901502620 | [6] | PUMP ELEMENT SUB ASSY (FOR M5 ONLY) | |
| 4. | VA0901401070 | [6] | VALVE SEAT | KOBDELIVERY VALVE ASSY (FOR M0,M2,M3 ONLY) |
| 4. | VA0901400780 | [6] | DELIVERY VALVE ASSY (FOR M5 ONLY) | |
| 4. | VA0901401250 | [6] | STD INLET VALVE | KOBSTD ENGINE INLET VALVE DELIVERY VALVE ASSY (FOR M2,M5 ONLY) Superseded by part number: VAME703516 |
| 5. | VA0901370110 | [6] | GASKET GASKET,DELIVERY/V | GASKET GASKET,DELIVERY/V |
| 6. | VA0901360490 | [6] | SPRING,DELIVERY/V (FOR M0,M5 ONLY) | |
| 6. | VA0901360630 | [6] | SPRING,DELIVERY/V (FOR M2,M3,M4 ONLY) | |
| 6A. | VA0901330140 | [6] | STOPPER,DELIVERY/V | |
| 6B. | VA9080110180 | [6] | O-RING | KOBO-RING |
| 6C. | VA9020804610 | [1] | WASHER T = 0.1 | |
| 6C. | VA9021804620 | [1] | WASHER T = 0.2 | |
| 6C. | VA9490135140 | [1] | WASHER T=0.15 | |
| 7. | VA0901310420 | [6] | CLAMP | KOBHOLDER,DELIVERY/V |
| a. | VA0902120010 | [1] | RACK,CONTROL | |
| 9. | VA0902150010 | [1] | SCREW,GUIDE | |
| 10. | VA0901610160 | [6] | SLEEVE,CONTROL (FOR M0,M3 ONLY) | |
| 10. | VA0901610330 | [6] | SLEEVE,CONTROL (FOR M2,M4,M5 ONLY) | |
| 11. | VA0901560010 | [6] | PINION,CONTROL | |
| 12. | VA0901570010 | [6] | SCREW,CLAMP | |
| 13. | VA0901630010 | [6] | SEAT,SPG UPPER | |
| 14. | VA0901640010 | [6] | SPRING,PLUNGER | |
| 15. | VA0901650010 | [6] | SEAT,SPG LOWER | |
| 16. | VA0901700130 | [6] | TAPPET ASSY | |
| 17. | VA0901890060 | [6] | PLUG,SCREW | |
| 18. | VA0901910620 | [1] | CAMSHAFT | |
| 20. | VA9491010120 | [1] | BEARING,ROLLER | |
| 20A. | VA9491010071 | [1] | BEARING,ROLLER | |
| 21. | VA0901930020 | [1] | RING,ADJUST | |
| 21A. | VA0901930050 | [1] | RING,ADJUST | |
| 23. | VA0902010351 | [1] | COVER,BRG | |
| 29-29D. | VA0902700691 | [1] | COVER PLATE ASSY | |
| 29. | VA0902600130 | [1] | PLATE,COVER | |
| 29C. | VA0902430030 | [2] | PACKING PACKING | PACKING PACKING |
| 29D. | VA0902760020 | [2] | SCREW | |
| 31. | VA0902300031 | [3] | LOCK PLATE SET | |
| 37. | VA9491400060 | [1] | Q-RING | |
| 37A. | VA0902060040 | [1] | GASKET GASKET,BRG COVER | GASKET GASKET,BRG COVER |
| 39. | VA0903610040 | [1] | BEARING,CTR | |
| 40. | VA0903660021 | [2] | SCREW,GUIDE | |
| 41. | VA9490181030 | [2] | WASHER,PLAIN | |
| 43. | VA0903100170 | [1] | OVER FLOW VALVE ASSY (FOR M0,M3 ONLY) | |
| 43. | VA0903100080 | [1] | VALVE OVER FLOW VALVE ASSY (FOR M2,M4 ONLY) | VALVE OVER FLOW VALVE ASSY (FOR M2,M4 ONLY) |
| 43. | VA0903100110 | [1] | VALVE OVERF OVER FLOW VALVE ASSY (FOR M5 ONLY) | VALVE OVERF OVER FLOW VALVE ASSY (FOR M5 ONLY) |
| 44. | VA0902220070 | [4] | WASHER | KOBWASHER Superseded by part number: VA0594601401 |
| 45. | VA9491800310 | [1] | JACK SCREW | KOBSCREW,HOLLOW |
| 47. | VA9491400380 | [1] | O-RING 0-RING | O-RING 0-RING |
| 48. | VA9491800060 | [1] | SCREW | KOBSCREW,HOLLOW |
| 50. | VA0902510010 | [2] | WASHER | KOBWASHER |
| 51. | VA0901940010 | [1] | SHIM T=0.10 | |
| 51. | VA0901940020 | [1] | SHIM T=0.12 | |
| 51. | VA0901940030 | [1] | SHIM T=0.14 | |
| 51. | VA0901940040 | [1] | SHIM T=0.16 | |
| 51. | VA0901940050 | [1] | SHIM T=0.18 | |
| 51. | VA0901940060 | [1] | SHIM T=0.50 | |
| 51. | VA0901940110 | [1] | SHIM T=0.30 | |
| 51. | VA0901940290 | [1] | SHIM T=0.20 | |
| 51A. | VA0901940070 | [1] | SHIM T=0.10 | |
| 51A. | VA0901940080 | [1] | SHIM T=0.15 | |
| 51A. | VA0901940090 | [1] | SHIM T=0.30 | |
| 51A. | VA0901940100 | [1] | SHIM T=0.50 | |
| 54. | VA9141806201 | [4] | BOLT,W/WSR | |
| 55. | VA0900180081 | [1] | COVER,CONTROL RACK | |
| 56. | VA9490140210 | [1] | WA5HER, 5PG | |
| 57. | VA0900120220 | [1] | NUT,TIMER ROUND | |
| 55. | VA9491300210 | [1] | KEY,WOODRUFF | |
| 61. | VA9491402840 | [1] | O-RING 0-RING | O-RING 0-RING |
| 63. | VA9490502680 | [4] | NUT | |
| 64. | VA9490115020 | [4] | WASHER | |
| 65. | VA0900920100 | [1] | BRACKET | |
