现代零件查询R140W-7 PILOT HYD PIPING(BASE 3, -#0198)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
689 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
PILOT HYD PIPING
|
|
| 2. |
31N6-91230
|
[1] |
SOLENOID VLV-BREAKER
|
|
| 7. |
P930-082015
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 8. |
P930-122014
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 9. |
P933-122039
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 16. |
P840-042014
|
[1] |
HOSE ASSY-SYN THD
|
|
| 16. |
X400-042014
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 17. |
P840-062031
|
[1] |
HOSE ASSY-SYN THD
|
|
| 17. |
X400-042031
|
[1] |
HOSE ASSY-SYNFLEX,ORFS
|
|
| 20. |
P840-042044
|
[2] |
HOSE ASSY-SYN THD
|
|
| 20. |
X400-042044
|
[2] |
HOSE ASSY-ORFS 0X0
|
|
| 21. |
P840-062016
|
[1] |
HOSE ASSY-SYN THD
|
|
| 21. |
X400-062016
|
[1] |
HOSE ASSY-SYNFLEX,ORFS
|
|
| 23. |
P850-062022
|
[2] |
HOSE ASSY-SYN 0X45
|
|
| 23. |
X410-062022
|
[2] |
HOSE ASSY-ORFS 0X45
|
|
| 27. |
P860-042021
|
[1] |
HOSE ASSY-SYN 0X90
|
|
| 28. |
P860-042041
|
[1] |
HOSE ASSY-SYN 0X90
|
|
| 28. |
X420-042041
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 29. |
P860-062030
|
[1] |
HOSE ASSY-SYN 0X90
|
|
| 29. |
X420-062030
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 30. |
P860-062056
|
[1] |
HOSE ASSY-SYN 0X90
|
|
| 30. |
X420-062056
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 31. |
S621-011001
|
[10] |
O-RING
|
|
| 32. |
S621-012001
|
[8] |
O-RING
|
|
| 40. |
31N4-22130
|
[1] |
TEE
|
|
| 40. |
31N4-22140
|
[1] |
TEE-ORFS
|
|
| 41. |
31N6-22030
|
[1] |
TEE-SWIVEL NUT
|
|
| 41. |
X840-525151
|
[1] |
TEE-R/TYPE,SWIVEL,ORFS
|
|
| 44. |
X500-110004
|
[2] |
CONNECTOR-ORFS
|
|
| 46. |
X530-110004
|
[1] |
ELBOW-45,ORFS
|
|
| 49. |
P320-060406
|
[1] |
TEE-RUN TYPE
|
|
| 49. |
X820-065152
|
[1] |
TEE-R/TYPE,ORFS
|
|
| 51. |
P010-110002
|
[3] |
CONNECTOR
|
|
| 51. |
X500-110001
|
[3] |
CONNECTOR-ORFS
|
|
| 52. |
P010-110015
|
[1] |
CONNECTOR
|
|
| 52. |
X500-110015
|
[1] |
CONNECTOR-ORFS
|
|
| 53. |
P010-430002
|
[1] |
CONNECTOR
|
|
| 54. |
P010-430011
|
[1] |
CONNECTOR
|
|
| 55. |
P020-110001
|
[3] |
ELBOW-90
|
|
| 55. |
X520-110001
|
[3] |
ELBOW-90,ORFS
|
|
| 56. |
P020-110002
|
[1] |
ELBOW-90
|
|
| 56. |
X520-110002
|
[1] |
ELBOW-90,ORFS
|
|
| 59. |
P101-104043
|
[1] |
CONNECTOR-LONG
|
|
| 59. |
X511-104513
|
[1] |
CONNECTOR-LONG,ORFS
|
|
| 60. |
P220-110102
|
[1] |
PLUG
|
|
| 65. |
S621-014001
|
[3] |
O-RING
|
|
| 65. |
S621-014001
|
[2] |
O-RING
|
|
| 66. |
S621-018001
|
[4] |
O-RING
|
|
| 67. |
S631-011004
|
[7] |
O-RING
|
|
| 68. |
S631-014004
|
[3] |
O-RING
|
|
| 69. |
S631-018004
|
[1] |
O-RING
|
|
| 70. |
S631-024004
|
[3] |
O-RING
|
|
| 71. |
S651-810002
|
[1] |
NIPPLE-GREASE
|
|
| 73. |
S109-080556
|
[2] |
BOLT-SOCKET
|
|
| 74. |
S205-081002
|
[2] |
NUT-HEX
|
|
| 75. |
S403-082002
|
[2] |
WASHER-PLAIN
|
|
| 76. |
S411-080002
|
[2] |
WASHER-SPRING
|
|
| 77. |
S551-050203
|
[10] |
CLAMP-BAND
|
|
