凯斯零件查询(8465T) - CASE IH ROUND BALER W/TRACTOR HYDRAULICS (1/91-12/97) (9-84) - MESH WRAP HYD. CONTROL VALVE SERVICE KIT, 700124625 HYDRAULIC CONTROL VALVE SERVICE KIT COMPLETE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
712 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
700124625
|
[1] |
KIT
|
HFI
CONTROL VALVE SERVICE KIT COMPLETE
|
| 1. |
700711967
|
[1] |
VALVE
|
CAS
ASSEMBLY - control
|
| 2. |
413-428
|
[2] |
BOLT,Hex, 1/4" - 20 x 1-3/4", Gr 5
|
CAS
.25 X 1.75 UNC GR5 YZD Superseded by part number: 280164
|
| 3. |
231-5144
|
[2] |
SERRATED NUT,Flg, USR, 1/4"-20
|
CAS
Superseded by part number: 523282, 72187066
|
| 4. |
237-6004
|
[1] |
O-RING,0.072" Thk x 0.351" ID, -904, Cl 6, 90 Duro
|
CAS
4-1, 90 Duro, .351" ID x .072" Thk Superseded by part number: 165202, 72186131
|
| 5. |
218-5103
|
[1] |
90 ELBOW,90 Degree Elbow, 7/16" - 20 Male JIC x 7/16" - 20 Male ORB
|
CAS
90 DEGREE ELBOW (includes item 4) Superseded by part number: 216773
|
