现代零件查询R140W-7 LOWER HYD PIPING 1(4 OUTRIGGER)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
701 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 3. |
31ER-12010
|
[1] |
SELECTOR VALVE
|
|
| 4. |
31N5-70110
|
[1] |
PIPE ASSY
|
|
| 4. |
31N5-70111
|
[1] |
PIPE ASSY
|
|
| 5. |
31N5-70120
|
[1] |
PIPE ASSY
|
|
| 5. |
31N5-70121
|
[1] |
PIPE ASSY
|
|
| 12. |
31N5-70370
|
[2] |
HOSE ASS-ORFS
|
|
| 12. |
31N5-70371
|
[2] |
HOSE ASS-ORFS
|
|
| 13. |
31N4-70340
|
[2] |
HOSE ASSY
|
|
| 13. |
31N4-70341
|
[2] |
HOSE ASSY
|
|
| 14. |
31N4-70350
|
[1] |
HOSE ASSY
|
|
| 14. |
31N4-70351
|
[1] |
HOSE ASSY
|
|
| 15. |
P933-087010
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 15. |
P930-087010
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 17. |
P603-067027
|
[4] |
HOSE ASSY-THD
|
|
| 17. |
P913-067027
|
[4] |
HOSE ASSY-ORFS 0X0
|
|
| 20. |
P613-042024
|
[1] |
HOSE ASSY-THD 0X45
|
|
| 20. |
P923-042024
|
[1] |
HOSE ASSY-ORFS 0X45
|
|
| 20. |
P920-042024
|
[1] |
HOSE ASSY-ORFS 0X45
|
|
| 21. |
P623-042029
|
[1] |
HOSE ASSY-THD 0X90
|
|
| 21. |
P933-042029
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 21. |
P930-042029
|
[1] |
HOSE ASSY-ORFS 0X90
|
|
| 22. |
P010-110003
|
[4] |
CONNECTOR
|
|
| 22. |
X500-110002
|
[4] |
CONNECTOR-ORFS
|
|
| 23. |
P010-110013
|
[1] |
CONNECTOR
|
|
| 23. |
X500-110013
|
[1] |
CONNECTOR-ORFS
|
|
| 24. |
P020-110001
|
[1] |
ELBOW-90
|
|
| 24. |
X520-110001
|
[1] |
ELBOW-90,ORFS
|
|
| 25. |
P030-110001
|
[1] |
ELBOW-45
|
|
| 25. |
X530-110001
|
[1] |
ELBOW-45,ORFS
|
|
| 26. |
P173-160104
|
[4] |
FLANGE-HYD,SPLIT
|
|
| 27. |
P220-110102
|
[4] |
PLUG-CAP
|
|
| 28. |
P220-110104
|
[1] |
PLUG-HEX,HEAD
|
|
| 30. |
P310-060604
|
[1] |
TEE-BRANCH TYPE
|
|
| 30. |
X810-065251
|
[1] |
TEE-B/TYPE,ORFS
|
|
| 31. |
X500-110003
|
[6] |
CONNECTOR-ORFS
|
|
| 33. |
X710-100104
|
[4] |
CAP-HYD,ORFS
|
|
| 36. |
31EK-70370
|
[2] |
CLAMP-PIPE
|
|
| 38. |
S552-102370
|
[10] |
CLAMP-BAND
|
|
| 41. |
S017-100506
|
[4] |
BOLT-HEX
|
|
| 46. |
S109-101306
|
[8] |
BOLT-SOCKET
|
|
| 47. |
S205-101006
|
[8] |
NUT-HEX
|
|
| 48. |
S403-10100B
|
[12] |
WASHER-PLAIN
|
|
| 50. |
S411-100006
|
[4] |
WASHER-PLAIN
|
|
| 52. |
Y171-024004
|
[2] |
O-RING
|
|
| 53. |
S621-014001
|
[14] |
O-RING
|
|
| 54. |
S631-011004
|
[8] |
O-RING
|
|
| 55. |
S631-014004
|
[6] |
O-RING
|
|
| 56. |
S631-018004
|
[7] |
O-RING
|
|
| 57. |
S760-100800
|
[4] |
GROMMET
|
|
| 58. |
S621-011001
|
[4] |
O-RING
|
|
| 59. |
S621-012001
|
[8] |
O-RING(SEAL LOCK TYPE)
|
|
