纽荷兰零件查询(F4HFE613Y A005) - ENGINE 5801425075 - 84387923 (10.247.01) - INJECTION PUMP (504041280) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
400 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899003 | [3] | FLANGE NUT,M8 x 1.25 | TOR Superseded by part number: 17044735 |
| 2. | 4896952 | [1] | COVER | TOR |
| 3. | 16747224 | [3] | NUT | TORM8X1,25X50 Superseded by part number: 2852488 |
| 4. | 4890700 | [1] | GASKET,1.21mm Thk | TOR |
| 5. | 84385110 | [1] | FUEL PUMP | TORASSY |
| 5. | 84385110R | [1] | REMAN-INJECTION PUMP | TOR |
| 5. | 84385110C | [1] | CORE-INJECTION PUMP | TORReturn Number |
| 6. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 7. | 4890088 | [1] | O-RING,44mm ID x 3mm Width | TOR Superseded by part number: 42549209 |
| 8. | 4890634 | [1] | NUT | TORM18 x 1.5 |
| 9. | 4891385 | [4] | SEALING WASHER | TOR Superseded by part number: 42556616 |
| 10. | 4893962 | [4] | QUICK MALE COUPLING | TOR Superseded by part number: 42559146 |
| 11. | 2852804 | [1] | HUB | TORASSY Superseded by part number: 504041278 |
| 13. | 2852805 | [1] | O-RING | TOR |
| 14. | 4893389 | [1] | DRIVEN GEAR | TOR |
| 15. | 16586324 | [2] | BOLT,Hex, M8 x 20mm, Cl 8.8, Full Thd | TOR Superseded by part number: 16673635 |
| 16. | 4890635 | [1] | SPRING WASHER | TOR Superseded by part number: 17095814 |
