现代零件查询R140W-7 LOWER HYD PIPING(FRONT BLADE, #0340-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
616 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
FRONT DOZER BLADE PIPING
|
|
| 3. |
31N4-70511
|
[2] |
PIPE ASSY
|
|
| 4. |
31N4-70521
|
[1] |
PIPE ASSY
|
|
| 5. |
31N4-70531
|
[1] |
PIPE ASSY
|
|
| 6. |
P933-087028
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 7. |
P933-087011
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 8. |
P913-067016
|
[4] |
HOSE ASSY-ORFS 0X0
|
|
| 9. |
P913-047014
|
[1] |
HOSE ASSY-ORFS 0X0
|
|
| 10. |
X840-535353
|
[2] |
S/NUT TEE-R/TYPE,ORFS
|
|
| 11. |
X500-110003
|
[2] |
CONNECTOR-ORFS
|
|
| 12. |
X500-110002
|
[4] |
CONNECTOR-ORFS
|
|
| 13. |
X520-110001
|
[2] |
ELBOW-90,ORFS
|
|
| 14. |
S621-011001
|
[2] |
O-RING,ORFS
|
|
| 15. |
S621-012001
|
[8] |
O-RING,ORFS
|
|
| 16. |
S621-014001
|
[10] |
O-RING,ORFS
|
|
| 17. |
S631-011004
|
[4] |
O-RING
|
|
| 18. |
S631-014004
|
[4] |
O-RING
|
|
| 19. |
S631-018004
|
[3] |
O-RING
|
|
| 20. |
P220-110102
|
[2] |
PLUG-HEX
|
|
| 21. |
P220-110103
|
[1] |
PLUG
|
|
| 22. |
P220-110104
|
[1] |
PLUG-HEX
|
|
| 23. |
31E4-3030
|
[1] |
CLAMP-PIPE
|
|
| 24. |
31EE-50180
|
[2] |
CLAMP ASSY
|
|
| 25. |
31E4-31430
|
[1] |
SPACER-CLAMP
|
|
| 26. |
31E4-31440
|
[1] |
BRACKET-PIPE
|
|
| 27. |
S017-101002
|
[1] |
BOLT-HEX
|
|
| 28. |
S017-120602
|
[2] |
BOLT-HEX
|
|
| 29. |
S037-102522
|
[2] |
BOLT-W/WASHER
|
|
| 30. |
S205-101002
|
[1] |
NUT-HEX
|
|
| 31. |
S403-101006
|
[1] |
WASHER-PLAIN
|
|
| 32. |
S403-121002
|
[2] |
WASHER-PLAIN
|
|
| 33. |
S411-100002
|
[6] |
WASHER-SPRING
|
|
| 34. |
S411-120002
|
[2] |
WASHER-SPRING
|
|
| 35. |
S552-102370
|
[10] |
CLAMP-BAND
|
|
