凯斯零件查询(8465T) - CASE IH ROUND BALER W/TRACTOR HYDRAULICS (1/91-12/97) (4-16) - ELECTRICAL HARNESS SERVICE PARTS, CONTINUED Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
353 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700707002
|
[1] |
REPAIR KIT
|
IH
FOUR WAY - connector repair kit, female (includes items 2, 3 and 4) Superseded by part number: 225123C1, 87692817, 84286327
|
| 2. |
700706400
|
[1] |
PLUG
|
IH
SEAL Superseded by part number: 84286327
|
| 3. |
700708760
|
[1] |
ELEC. TERMINAL PIN,18 - 20 SAE
|
IH
- socket (18-20 gauge wire) Superseded by part number: 225123C1
|
| 4. |
700708963
|
[1] |
WIRE CONNECTOR
|
CAS
FOUR WAY - connector, female Superseded by part number: 87692817
|
| 5. |
1301191C1
|
[1] |
CONNECTION
|
IH
RING - coupling (#17 plug arrangement) Superseded by part number: 86594691
|
| 6. |
700709232
|
[1] |
POWER SOCKET
|
CAS
RECEPTACLE - standard sex (4 pin)
|
| 7. |
700713574
|
[1] |
SOCKET
|
CAS
CONTACT - female
|
| 8. |
1994741C1
|
[1] |
CONTACT HOUSING
|
CAS
CLAMP (shell size 11)
|
| 9. |
1714005
|
[1] |
PACKAGE,SERVICE
|
IH
KIT - harness repair (female end) Superseded by part number: 700710620, 87675194, 900401, 84471900
|
| 10. |
700712135
|
[1] |
WIRE HARNESS
|
CAS
HARNESS - wire
|
| 11. |
700707014
|
[1] |
TERMINAL CONNECTOR
|
CAS
TOOL CONNECTOR REPAIR Superseded by part number: 1964864C1
|
| 12. |
700715341
|
[1] |
PLUG
|
CAS
- 7 pin domestic Superseded by part number: 361428
|
| 13. |
700708964
|
[1] |
WIRE CONNECTOR
|
CAS
FOUR WAY - connector, male Superseded by part number: 87692802
|
| 14. |
700706401
|
[1] |
TERMINAL
|
CAS
PIN - terminal (18-20 gauge wire) Superseded by part number: 225120C1
|
| 15. |
700709354
|
[1] |
REPAIR KIT
|
IH
FOUR WAY - shroud connector repair kit (includes items 2, 8 and 9) Superseded by part number: 87692802, 84286327, 225120C1
|
