纽荷兰零件查询(F5CE5454B A005) - ENGINE 504387947 - 84230116 (10.101.AA) - CYLINDER HEAD & RELATED PARTS New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
413 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504385846 | [1] | CYLINDER HEAD,4 Cylinder | TORIncl 2, 3, 6, 7 |
| 1. | 47573576R | [1] | REMAN-CYLINDER HEAD | RACC232 COMPACT TRACK LOADER, L225 SKID STEER LOADER, Both (4/11-), F5CE5454B A005 ENGINE 504387947 - 84230116 |
| 1. | 47573576C | [1] | CORE-CYLINDER HEAD | RACReturn Number |
| 2. | 504162949 | [4] | VALVE SEAT | TOR |
| 3. | 4749397 | [8] | VALVE GUIDE,Std | TOR |
| 3. | 4749398 | [8] | VALVE GUIDE,+0.10 | TOR |
| 3. | 4749399 | [8] | VALVE GUIDE,+0.2 | TOR |
| 4. | 99435557 | [3] | DOWEL,8.50mm Dia | TOR Superseded by part number: 2852481 |
| 5. | 17281481 | [1] | O-RING,10.7mm ID x 2.6mm Width | LEC Superseded by part number: 14456981 |
| 6. | 504254094 | [4] | VALVE SEAT | TOR |
| 7. | 16988301 | [8] | PLUG | TOR |
| 8. | 504162958 | [4] | STD INLET VALVE | TOR |
| 9. | 504162959 | [4] | STD EXHAUST VALVE | TOR |
| 10. | 504178119 | [8] | RETAINER CUP | TOR |
| 11. | 4812347 | [8] | SPRING | TOR |
| 12. | 4780558 | [8] | CUP | TOR |
| 13. | 40101574 | [8] | GASKET | SM Superseded by part number: 40101573 |
| 14. | 14196670 | [16] | ROCKER ARM COTTER | TOR Superseded by part number: 4819891 |
| 15. | 504081521 | [6] | BOLT,M15 x 1.5 x 193mm | TOR |
| 16. | 504081533 | [4] | BOLT,M12 x 1.5 x 165mm | TOR |
| 17. | 504190831 | [1] | CYLINDER HEAD GASKET | TOR |
| 18. | 4838680 | [8] | CAP | TOR |
| 19. | 500380521 | [8] | STUD | TOR |
| 20. | 16990970 | [1] | PLUG,Lock, 30mm Dia | TOR |
| 21. | 10300511 | [1] | PLUG,M12 x 1.5 x 12, Cl5.8 | JES |
| 22. | 2854292 | [1] | SEALING WASHER,12mm ID x 17mm OD x 1.5mm Thk | TOR Superseded by part number: 10298460 |
