纽荷兰零件查询(F5CE5454B A005) - ENGINE 504387947 - 84230116 (10.102.AK) - ENGINE BLOCK FRONT COVER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
307 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504244214 | [1] | COVER | TORTiming Gear Housing, Incl 2, 3 |
| 2. | 504051236 | [1] | PLUG,Threaded, 1/8" | TOR |
| 3. | 504204989 | [1] | LUBE OIL NOZZLE | TOR |
| 4. | 504389774 | [1] | Front Crankcase Cover | COVER |
| 5. | 504244287 | [1] | GASKET | TOR |
| 6. | 16673735 | [4] | BOLT,Hex, M8 x 1.25 x 25mm | TOR Superseded by part number: 10278301 |
| 7. | 16586625 | [13] | BOLT,M8 x 35mm | TOR |
| 8. | 4798845 | [2] | BOLT,M8 x 1.25 x 16.50mm | TOR |
| 9. | 10300611 | [1] | PLUG,M14 x 1.5 x 14, Cl5.8 | BAS Superseded by part number: 16992315 |
| 10. | 4858608 | [1] | SEAL,14mm ID x 19.50mm OD x 1.50mm Thk | TTF Superseded by part number: 2852356 |
| 11. | 99435557 | [4] | DOWEL,8.50mm Dia | TOR Superseded by part number: 2852481 |
| 12. | 16586925 | [6] | BOLT,M8 x 50mm | TOR |
| 13. | 98401723 | [5] | BOLT,Hex, M8 x 1.25 x 12mm | TOR |
| 14. | 2995644 | [1] | SEALANT | TORNot Illustrated |
