纽荷兰零件查询(F5CE5454B A005) - ENGINE 504387947 - 84230116 (10.103.AA) - CRANKSHAFT New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
1013 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504213230 | [1] | CRANKSHAFT | TORIncl 2 - 6 Superseded by part number: 17236324, 504240426, 504276025 |
| 1. | 504276025R | [1] | REMAN-CRANKSHAFT | TOR |
| 1. | 504276025C | [1] | CORE-CRANKSHAFT | TORReturn Number |
| 2. | 504240426 | [1] | GEAR | TORCamshaft Pinion |
| 3. | 504023782 | [1] | GEAR | TORCamshaft Pinion |
| 4. | 500374310 | [3] | SCREW | TOR |
| 5. | 504006981 | [1] | COTTER PIN | TOR |
| 6. | 17236324 | [1] | SPLIT PIN,4mm Dia | TOR |
| 7. | 504014232 | [1] | SEAL | TOR |
| 8. | 504056152 | [1] | SEAL | TOR |
| 9. | 2995574 | [1] | SET OF STD MAIN BRGS | TOR Superseded by part number: 500054637 |
| 9. | 2995575 | [1] | SET OF MAIN BRGS -0.254 | TOR Superseded by part number: 500054638 |
| 9. | 2995576 | [1] | SET OF MAIN BRGS -0.508 | TOR Superseded by part number: 500054639 |
