| 1. |
218-5105
|
[2] |
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
(includes item 5) 90º, 9/16"-18, 37º x 9/16"-18, O-Ring Superseded by part number: 76344, 72186128
|
| 2. |
700707286
|
[2] |
HOSE
|
CAS
- hydraulic
|
| 3. |
218-5172
|
[1] |
ELBOW,45 Degree Elbow, 9/16" - 18 Male JIC x 9/16" - 18 Female JIC
|
CAS
- 45 degrees Superseded by part number: 86512959
|
| 4. |
218-5243
|
[1] |
TEE,9/16" - 18 Male JIC x 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
Straight run (Includes item 5) 9/16"-18, 37º x 9/16"-18, O-Ring Run Superseded by part number: 86513020
|
| 5. |
738468
|
[4] |
O-RING
|
IH
|
| 6. |
218-5182
|
[1] |
TEE,9/16" - 18 Male JIC x 9/16" - 18 Male JIC x 9/16" - 18 Male ORB
|
CAS
- straight thread (includes item 5) Superseded by part number: 163335
|
| 7. |
700712156
|
[1] |
CYLINDER
|
CAS
ASSEMBLY - hydraulic
|
| 8. |
62653
|
[1] |
CLEVIS PIN
|
IH
5/8 X 3 CLEVIS PIN Superseded by part number: 87034825
|
| 9. |
700708068
|
[3] |
CLEVIS PIN,15.77mm OD x 68.66mm L
|
IH
5/8 X 2-1/2 CLEVIS PIN
|
| 10. |
432-1016
|
[4] |
COTTER PIN,5/32" x 1"
|
CAS
5/32" x 1" Superseded by part number: 83903970
|
| 11. |
121-226
|
[1] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 12. |
231-5146
|
[1] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 13. |
700118823
|
[1] |
PIN
|
IH
WA
|
| 14. |
396-21066
|
[3] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 15. |
700120671
|
[1] |
CLAMP
|
IH
COLLAR
|
| 16. |
700712157
|
[1] |
CYLINDER
|
CAS
ASSEMBLY - hydraulic
|
| 17. |
461-33116
|
[4] |
HEX SOC SCREW,5/16"-18 x 1"
|
CAS
5/16-18 X 1 HSHCS SPL Superseded by part number: 87020811
|
| 18. |
700710626
|
[1] |
CYLINDER
|
CAS
ASSEMBLY - hydraulic (S.N. CFH0074001 thru CFH0074011)
|
| . . |
700712159
|
[1] |
CYLINDER ASSY.
|
IH
CYLINDER ASSEMBLY - hydraulic (S.N. CFH0074012 and later)
|
