纽荷兰零件查询(F5CE5454B A005) - ENGINE 504387947 - 84230116 (10.218.AF) - INJECTOR New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
851 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504385978 | [4] | FUEL SYSTEM INJECTOR | TORIncl 6, 7 |
| 1. | 504385978R | [4] | REMAN-INJECT NOZZLE | TOR |
| 1. | 504385978C | [4] | CORE-NOZZLE, INJECT | TORReturn Number |
| 2. | 504385832 | [4] | BRACKET | TOR |
| 3. | 504315404 | [4] | STUD,M8 x 16 x 60mm | TOR |
| 4. | 500353601 | [4] | WASHER | TOR |
| 5. | 17044735 | [4] | NUT,Hex, M8 | TOR |
| 7. | 4899689 | [4] | SEALING WASHER,7mm ID x 15mm OD x 1.5mm Thk | TOR |
