纽荷兰零件查询(F5CE5454B A005) - ENGINE 504387947 - 84230116 (10.250.AC) - TURBOCHARGER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
233 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504242763 | [1] | TURBOCHARGER | TOR |
| 1. | 504242763R | [1] | REMAN-TURBOCHARGER | TORSR220, SV250, C232, L225 ALL (4/11-), F5CE5454B A005 ALL ENGINE 504387947 - 84230116 |
| 1. | 504242763C | [1] | CORE-TURBOCHARGER | TORReturn Number |
| 2. | 4899343 | [1] | GASKET,0.45mm Thk | TORExhaust Manifold |
| 3. | 500370706 | [1] | GASKET | JES |
| 4. | 500322677 | [4] | NUT,M8 | LEC |
| 5. | 504164226 | [1] | PIPE | TOROil, Outlet, Incl 12 |
| 6. | 504164224 | [1] | PIPE | TOROil, Inlet |
| 7. | 4864080 | [1] | BANJO BOLT,M10 x 1.25 | LEC |
| 8. | 17750480 | [2] | SEAL,12.2mm ID x 17.8mm OD x 1.5mm Thk | TOR |
| 9. | 16586225 | [1] | BOLT,M8 x 16mm | TOR |
| 10. | 18137825 | [2] | BOLT,Hex, M6 x 16mm | TOR |
| 11. | 13550304 | [4] | WASHER | TOR |
| 12. | 14457181 | [1] | O-RING,13.94mm ID x 2.62" Width | TTF Superseded by part number: 17281681 |
