现代零件查询R140W-7 ROCKER LEVERS(#0072-)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
995 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
ROCKER LEVERS
|
|
| . |
3922488
|
[4] |
SHAFT-R/LEVER
|
|
| 1. |
3911423
|
[1] |
SUPPORT-R/LEVER
|
|
| 1. |
3922487
|
[1] |
SHAFT-R/LEVER
|
|
| 2. |
3910811
|
[4] |
LEVER-ROCKER
|
|
| 2. |
3910809
|
[1] |
LEVER-ROCKER
|
|
| 3. |
3937438
|
[1] |
SCREW
|
|
| 4. |
3927692
|
[1] |
NUT-HEAVY HEX
|
|
| N5. |
3900705
|
[1] |
INSERT-R/LEVER
|
|
| 6. |
3910810
|
[4] |
LEVER-ROCKER
|
|
| 6. |
3910808
|
[1] |
LEVER-ROCKER
|
|
| 3. |
3937438
|
[1] |
SCREW
|
|
| 4. |
3927692
|
[1] |
NUT-HEAVY HEX
|
|
| N5. |
3900705
|
[1] |
INSERT-R/LEVER
|
|
| 7. |
3900245
|
[8] |
WASHER-PLAIN
|
|
| 8. |
3900242
|
[8] |
RING-RETAINING
|
|
| 9. |
3901221
|
[4] |
SCREW
|
|
| 10. |
3920781
|
[4] |
SCREW
|
|
| 11. |
3284377
|
[8] |
ROD-PUSH
|
|
| N. |
@
|
[AR] |
NOT INDIVIDUALLY SUPPLIED
|
|
