凯斯零件查询(8465T) - CASE IH ROUND BALER W/TRACTOR HYDRAULICS (1/91-12/97) (6-18) - POWERED RIENK ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
342 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
617863R1
|
[4] |
FLANGED BEARING
|
IH
- 72 mm
|
| 2. |
51292
|
[2] |
SPHERICAL BEARING,1.25" ID x 72 mm OD x 19 mm
|
IH
Superseded by part number: 84330041, 47508357
|
| 3. |
6869382
|
[6] |
SPACER
|
HFI
|
| 4. |
121-226
|
[6] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 5. |
232-5316
|
[10] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 6. |
409-7620
|
[2] |
BOLT,Hex Flg, 3/8" - 16 x 1 1/4", Spcl
|
CAS
- hex serrated flange, 3/8 NC x 1-1/4 inch Superseded by part number: 86512174
|
| 7. |
121-237
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl
|
CAS
3/8-16 X 1-1/4 HFS GR8 Superseded by part number: 87327172
|
| 8. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 9. |
700129350
|
[1] |
SUPPORT
|
HFI
WA Superseded by part number: 700133245
|
| . . |
700133245
|
[1] |
SUPPORT ASSY.
|
HFI
SUPPORT WA
|
| 10. |
700130748
|
[4] |
SHIM
|
HFI
|
| 11. |
700101218
|
[1] |
ADJUSTING PLATE
|
HFI
SHIM
|
| 12. |
700125920
|
[1] |
SUPPORT
|
HFI
|
| 13. |
700125160
|
[7] |
DISC
|
CAS
RIENK WA - inner Superseded by part number: 700133243
|
| . . |
700133243
|
[7] |
DISC
|
CAS
RIENK WA - inner
|
| 14. |
700712007
|
[1] |
NYLON BEARING,32.8 mm ID x 50.8 mm OD x 38 mm
|
CAS
BUSHING - nylon Superseded by part number: 700726045
|
| 15. |
700125917
|
[1] |
SUPPORT
|
HFI
WA
|
| 16. |
700124599
|
[2] |
DISC
|
CAS
RIENK WA - outer Superseded by part number: 700133242
|
| . . |
700133242
|
[2] |
WHEEL
|
HFI
RIENK WA - outer
|
| 17. |
700126362
|
[1] |
SHAFT
|
HFI
- hex
|
| 18. |
433-628
|
[6] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 3/4", Gr 5
|
CAS
3/8-16 X 1-3/4 RHSNB Superseded by part number: 86508775
|
| 19. |
231-5146
|
[6] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
