凯斯零件查询(8465T) - CASE IH ROUND BALER W/TRACTOR HYDRAULICS (1/91-12/97) (5-10) - TAILGATE ROLLER ASSEMBLY, SERIAL NUMBER CFH0074856 AND LATER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
859 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
413-1228
|
[4] |
BOLT,Hex, 3/4" - 10 x 1-3/4", Gr 5
|
CAS
3/4-10 x 1-3/4 C Superseded by part number: 88725
|
| 2. |
492-11075
|
[4] |
LOCK WASHER,3/4"
|
CAS
3/4" Superseded by part number: 87340
|
| 3. |
705566
|
[4] |
WASHER
|
IH
3/4 HARDENED PLAIN WASHER
|
| 4. |
1703453
|
[2] |
BOLT,Flat Hd, Csk, 1/2" - 13 x 1 1/4"
|
CAS
1/2-13 X 1-1/4 HSFCHCS
|
| 5. |
6467674
|
[2] |
SPACER
|
CAS
|
| 6. |
700707981
|
[2] |
SCREW,FLAT, 3/4" - 10 x 1-3/4"
|
L
3/4-10 X 1-3/4 HSFCHCS
|
| 7. |
F82059
|
[2] |
BEARING ASSY,38.1mm ID x 80mm OD x 22mm W
|
IH
BEARING - cylindrical
|
| 8. |
8050825
|
[6] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
- cylindrical Superseded by part number: F82059
|
| 9. |
700130881
|
[1] |
ROLLER
|
HFI
WA
|
| 10. |
700130853
|
[1] |
SHAFT
|
HFI
|
| 11. |
700130852
|
[1] |
ROLLER
|
HFI
ASSEMBLY (includes items 7, 8, 9 & 10) Superseded by part number: 700130853
|
| 12. |
700125801
|
[1] |
ROLLER
|
CAS
ASSEMBLY (includes item 13)
|
| 13. |
586156R92
|
[2] |
BEARING, ROLLER, CYL,0.7505" ID x 47 mm OD x 0.8437, 0.53125"
|
IH
BEARING - cylindrical Superseded by part number: 76802
|
| 14. |
700129347
|
[1] |
SHAFT
|
HFI
- roller
|
| 15. |
700100927
|
[4] |
HUB
|
L
|
| 16. |
700124612
|
[2] |
ROLLER
|
CAS
ASSEMBLY (includes item 8)
|
