纽荷兰零件查询(F5CE5454C A003) - ENGINE 504387948 - 84171653 (10.101.01) - CYLINDER HEAD & RELATED PARTS (504385845) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
663 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504385846 | [1] | CYLINDER HEAD,4 Cylinder | TOR- ASSY Include Ref 2,3,6,7 |
| 1. | 47573576R | [1] | REMAN-CYLINDER HEAD | RACC238, TR320, TV380, All COMPACT TRACK LOADER, L230, SR250, SV300, All SKID STEER LOADER, All ASSY (4/11-), F5CE5454C A003 ENGINE 504387948 - 84171653, ASSY |
| 1. | 47573576C | [1] | CORE-CYLINDER HEAD | RACReturn Number |
| 2. | 504162949 | [4] | VALVE SEAT | TOR |
| 3. | 4749397 | [8] | VALVE GUIDE,Std | TOR+0,05 mm |
| 3. | 4749398 | [8] | VALVE GUIDE,+0.10 | TOR+0,1 mm |
| 3. | 4749399 | [8] | VALVE GUIDE,+0.2 | TOR+0,25 mm |
| 4. | 99435557 | [3] | DOWEL,8.50mm Dia | TORD. 8,5 mm Superseded by part number: 2852481 |
| 5. | 17281481 | [1] | O-RING,10.7mm ID x 2.6mm Width | LECD. 10,7 mm SP=2,6 mm Superseded by part number: 14456981 |
| 6. | 504254094 | [4] | VALVE SEAT | TOR |
| 7. | 16988301 | [8] | PLUG | TORD. 20 mm |
| 8. | 504162958 | [4] | STD INLET VALVE | TORSTD ENGINE INLET VALVE |
| 9. | 504162959 | [4] | STD EXHAUST VALVE | TORSTD ENGINE EXHAUST VALVE |
| 10. | 504178119 | [8] | RETAINER CUP | TOR |
| 11. | 4812347 | [8] | SPRING | TOR |
| 12. | 4780558 | [8] | CUP | TOR |
| 13. | 40101574 | [8] | GASKET | SM Superseded by part number: 40101573 |
| 14. | 14196670 | [16] | ROCKER ARM COTTER | TORD. 7,85 mm Superseded by part number: 4819891 |
| 15. | 504081521 | [6] | BOLT,M15 x 1.5 x 193mm | TORM15X1,5X193 mm |
| 16. | 504081533 | [4] | BOLT,M12 x 1.5 x 165mm | TORM12X1,5X165 mm |
| 17. | 504190831 | [1] | CYLINDER HEAD GASKET | TORSP 0,8 |
| 18. | 4838680 | [8] | CAP | TOR |
| 19. | 500380521 | [8] | STUD | TORM8 x 1.25 x 45 |
| 20. | 16990970 | [1] | PLUG,Lock, 30mm Dia | TOR |
| 21. | 10300511 | [1] | PLUG,M12 x 1.5 x 12, Cl5.8 | JES |
| 22. | 2854292 | [1] | SEALING WASHER,12mm ID x 17mm OD x 1.5mm Thk | TOR Superseded by part number: 10298460 |
