凯斯零件查询(8465T) - CASE IH ROUND BALER W/TRACTOR HYDRAULICS (1/91-12/97) (5-14) - TAILGATE ROLLER SHAFT ASSEMBLY, TAILGATE ROLLER SHAFT ASSEMBLY SHOWN BELOW IS OPTIONAL Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
570 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700128304
|
[2] |
WASHER
|
HFI
- special
|
| 2. |
Q1443
|
[2] |
KEY,5/16" Sq x 1 1/2", Par
|
IH
5/16 X 5/16 X 1-1/2 KEY
|
| 3. |
700128303
|
[2] |
HUB
|
HFI
|
| 4. |
100-11150
|
[4] |
SNAP RING,#150, Ext
|
CAS
Ring, Snap, #150, Ext Superseded by part number: 133066
|
| 5. |
700710914
|
[2] |
BEARING, ROLLER, CYL,55.56mm ID x 100mm OD x 24mm W
|
L
BEARING - cylindrical
|
| 6. |
700128301
|
[1] |
SHAFT
|
HFI
ASM. (includes items 2, 3 and 4)
|
| 7. |
700125073
|
[1] |
ROLLER
|
HFI
ASSEMBLY (includes item 5)
|
| . . |
700130852
|
[1] |
ROLLER
|
HFI
ASSEMBLY (includes item 5) Superseded by part number: 700130853
|
