纽荷兰零件查询(F5CE5454C A003) - ENGINE 504387948 - 84171653 (10.101.02[01]) - ROCKER SHAFT (504335547) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
624 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504345342 | [1] | VALVE COVER | TOR |
| 2. | 504250345 | [1] | SHAFT | TOR |
| 3. | 16987801 | [2] | PLUG,Lock, M12 | BRED. 12 mm Superseded by part number: 14328301 |
| 4. | 99454296 | [1] | SCREW | TOR |
| 5. | 5801572084 | [4] | ROCKER ARM | TOR |
| 6. | 504221914 | [4] | ROCKER ARM | TOR |
| 7. | 14457181 | [1] | O-RING,13.94mm ID x 2.62" Width | TTFD. 13,9 mm SP=2,6 mm Superseded by part number: 17281681 |
| 8. | 4699783 | [8] | ADJUSTMENT SCREW | TOR |
| 9. | 4338920 | [8] | NUT | TOR |
| 10. | 14328801 | [1] | PLUG,M22, Tapered | JESD. 22 mm |
| 11. | 16586524 | [9] | FLANGE BOLT,Hex Flat Hd, M8 x 1.25 x 30mm, Cl 8.8 | TORM8 x 50 Superseded by part number: 16673835 |
| 12. | 16673835 | [11] | BOLT,Hex, M8 x 30mm | TORM8 x 30 |
| 13. | 504163121 | [1] | GASKET | TOR |
| 14. | 504177226 | [1] | GASKET | TOR |
| 15. | 504273002 | [4] | PLUG,M12 x 1.5 | TORM12X1,5 mm |
