| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| . | @ | [1] | OIL LEVEL GAUGE | LG90K822 |
| 1. | 3283354 | [1] | TUBE-OIL GAUGE | |
| 2. | 3863405 | [1] | CLIP | |
| 3. | 3863630 | [1] | DIPSTICK | |
| N5. | 3864013 | [2] | BRACKET-CONNECTION | |
| N6. | 3864014 | [1] | SPACER-MOUNTING | |
| 7. | 3864015 | [1] | ISOLATOR-VIBRATION | |
| N8. | 3864016 | [1] | SPACER-MOUNTING | |
| N9. | 3864018 | [1] | SCREW | |
| 10. | 3900589 | [2] | NUT-HEX FLANGE | |
| 12. | 3900632 | [1] | SCREW | |
| 13. | 3900955 | [3] | PLUG-EXPANSION | |
| N. | @ | [AR] | NOT INDIVIDUALLY SUPPLIED |
