纽荷兰零件查询(F5CE5454C A003) - ENGINE 504387948 - 84171653 (10.106.01) - CAMSHAFT - TIMING CONTROL (504228067) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
961 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504272265 | [1] | CAMSHAFT | TOR- ASSY |
| 1. | 504272265R | [1] | REMAN-CAMSHAFT | RACC238, TR320, TV380 V38VNT (V38VET), All COMPACT TRACK LOADER, L230, SR250, SV300, All SKID STEER LOADER, All (4/11-), F5CE5454C A003 ENGINE 504387948 - 84171653, All ASSY |
| 1. | 504272265C | [1] | | RACReturn Number |
| 2. | 10839510 | [1] | DOWEL,M6 x 9 | TTF Superseded by part number: 17275310 |
| 3. | 4897457 | [1] | SUPPORT | TOR |
| 4. | 98471524 | [8] | TAPPET | TOR+0,0 |
| 5. | 504163240 | [8] | PUSH ROD | TOR |
| 6. | 16673635 | [2] | BOLT,Hex, M8 x 1.25 x 20mm, Full Thd | TOR Superseded by part number: 16978124 |
| 7. | 504240396 | [1] | GEAR | TOR |
