700126758
|
[1] |
KIT
|
HFI
PICKUP BELT DRIVE KIT COMPLETE
|
| 1. |
413-820
|
[1] |
BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 72187215, 87670
|
| 2. |
855064
|
[1] |
V-BELT,0.88" W x 69.00" L
|
HFI
|
| 3. |
700120270
|
[1] |
WASHER
|
CAS
- special
|
| 4. |
95-81100
|
[6] |
WASHER,33/64" x 7/8" x .049"
|
CAS
1/2 X 18 GAUGE NRMB Superseded by part number: 86639334
|
| 5. |
700126998
|
[1] |
SHEAVE
|
HFI
WA
|
| 6. |
662958R91
|
[1] |
PULLEY
|
IH
IDLER
|
| 7. |
858167
|
[1] |
SPRING
|
L
- extension
|
| 8. |
219-8
|
[3] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 9. |
195-2139
|
[4] |
WASHER,36.52mm ID x 57.15mm OD x 2.03mm Thk
|
IH
1-3/8 X 18 GAUGE NRMB
|
| 10. |
700126742
|
[1] |
ARM
|
HFI
WA
|
| 11. |
6179220
|
[1] |
SPACER
|
HFI
|
| 12. |
413-1052
|
[1] |
BOLT,Hex, 5/8" - 11 x 3-1/4", Gr 5
|
CAS
5/8-11 X 3-1/4 C Superseded by part number: 9827853
|
| 13. |
492-11062
|
[2] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 14. |
425-1010
|
[2] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 15. |
700116106
|
[1] |
SPACER
|
HFI
|
| 16. |
700126745
|
[1] |
SHIELD
|
HFI
WA
|
| 17. |
700126747
|
[1] |
SHIELD
|
HFI
WA
|
| 18. |
413-616
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 19. |
495-21044
|
[1] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 20. |
492-11038
|
[5] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 21. |
425-106
|
[7] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 22. |
256873
|
[2] |
BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd
|
NH
|
| 23. |
231-5145
|
[2] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 24. |
700126751
|
[1] |
SUPPORT
|
HFI
WA - left
|
| 25. |
700126754
|
[1] |
SUPPORT
|
HFI
|
| 26. |
413-1056
|
[1] |
BOLT,Hex, 5/8" - 11 x 3-1/2", Gr 5
|
CAS
Superseded by part number: 280119
|
| 27. |
396-21066
|
[1] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 28. |
496-11041
|
[1] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 29. |
413-640
|
[4] |
BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5
|
CAS
Superseded by part number: 87936
|
| 30. |
6136964
|
[1] |
SPACER
|
HFI
|
| 31. |
51200285
|
[1] |
SCREW
|
CAS
DRAWBOLT
|
| 32. |
700120259
|
[1] |
SHEAVE
|
HFI
|
