| 1. |
700709596
|
[1] |
GEARBOX ASSY
|
CAS
GEARBOX ASSEMBLY COMPLETE Superseded by part number: 700725329
|
| 2. |
700120864
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET WA - 60A16 tooth
|
| 3. |
740860
|
[1] |
RING, SNAP
|
CAS
RING - retaining, external Superseded by part number: 133066
|
| 4. |
52712
|
[8] |
BUSHING
|
CAS
1-1/2 X 18 GAUGE NRMB
|
| 5. |
1355D
|
[1] |
CHAIN (AG)
|
IH
CHAIN - roller, double #60
|
| 6. |
700120849
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET ASSEMBLY - 16 tooth (Includes Items 7 and 8)
|
| 7. |
852459
|
[2] |
BRONZE BUSHING
|
CAS
BUSHING - bronze
|
| 8. |
700120850
|
[2] |
SLEEVE
|
HFI
- shear
|
| 9. |
700120854
|
[1] |
SHAFT
|
HFI
ASSEMBLY (Includes Item 8)
|
| 10. |
413-428
|
[1] |
BOLT,Hex, 1/4" - 20 x 1-3/4", Gr 5
|
CAS
.25 X 1.75 UNC GR5 YZD Superseded by part number: 280164
|
| 11. |
232-4114
|
[1] |
LOCK NUT,1/4"-20, GC
|
CAS
1/4-20 HTLN GR B Superseded by part number: 280129
|
| 12. |
241-1326
|
[1] |
LINK,12.7mm Pitch
|
CAS
CONNECTOR - link #60 R/C
|
| 13. |
433-820
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| 14. |
80679
|
[8] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 15. |
425-108
|
[4] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, 1/2"-13, G5 Superseded by part number: 280431
|
| 16. |
619333R1
|
[2] |
FLANGED BEARING
|
IH
- bearing
|
| 17. |
664598R11
|
[1] |
COLLAR
|
IH
BEARING - spherical
|
| 18. |
495-21106
|
[1] |
WASHER,1"
|
CAS
1 HARDENED PLAIN WASHER Superseded by part number: 87374
|
| 19. |
52183
|
[2] |
BUSHING
|
CAS
3/4 X 18 GAUGE NRMB Superseded by part number: Z52183
|
| 20. |
700120858
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET WA 16 TOOTH
|
| 21. |
432-1640
|
[1] |
COTTER PIN,1/4" x 2 1/2"
|
CAS
Pin, Split (Cotter), 1/4" x 2 1/2" Superseded by part number: 80752
|
| 22. |
700710455
|
[1] |
CHAIN (AG)
|
CAS
CHAIN - roller, o-ring #80, 1" pitch 97 links plus #80 connector link (Item 23)
|
| 23. |
700710454
|
[1] |
CONNECTOR, ELEC
|
CAS
LINK - connector, #80 R/C
|
| 24. |
51200277
|
[2] |
SPROCKET ASSY.
|
CAS
SPROCKET - idler 12 tooth
|
| 25. |
432-1224
|
[1] |
COTTER PIN,3/16" x 1-1/2"
|
CAS
3/16" x 1 1/2" Superseded by part number: 80754
|
| 26. |
52928
|
[1] |
WASHER
|
CAS
3/4 X 14 GAUGE WRMB
|
| 27. |
413-1236
|
[1] |
BOLT,Hex, 3/4" - 10 x 2-1/4", Gr 5
|
CAS
- hex, 3/4 NC x 2-1/4 inch Superseded by part number: 87403
|
| 28. |
492-11075
|
[2] |
LOCK WASHER,3/4"
|
CAS
3/4" Superseded by part number: 87340
|
| 29. |
425-1012
|
[2] |
NUT,3/4"-10, G5
|
CAS
Superseded by part number: 280954
|
| 30. |
6537310
|
[1] |
SPACER
|
HFI
|
| 31. |
700120844
|
[1] |
ARM
|
HFI
ASSEMBLY - idler (Includes Item 32)
|
| 32. |
740787
|
[1] |
BRONZE BUSHING
|
CAS
BUSHING - bronze
|
| 33. |
700713654
|
[1] |
SPRING
|
CAS
- extension
|
| 34. |
705566
|
[4] |
WASHER
|
IH
3/4 HARDENED PLAIN WASHER
|
| 35. |
11-1248
|
[1] |
CARRIAGE BOLT,Short NK, 3/4"-10 x 7 1/2", G2
|
CAS
3/4-10 X 3 RHSNB
|
| 36. |
413-836
|
[4] |
BOLT,Hex, 1/2" - 13 x 2-1/4", Gr 5
|
CAS
Superseded by part number: 87975
|
| 37. |
700100892
|
[4] |
SPACER
|
CAS
|
