纽荷兰零件查询(F5CE5454C A003) - ENGINE 504387948 - 84171653 (10.408.02) - HEAT EXCHANGER (504154694) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
734 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504155542 | [1] | BODY | TOR |
| 2. | 504155544 | [1] | GASKET | TOR |
| 3. | 504164307 | [1] | OIL COOLER | TOR |
| 4. | 10275011 | [2] | PLUG,M22 x 1.5 x 13 | JESM22X1,5 mm |
| 5. | 87332142 | [2] | SEALING WASHER,23.5mm ID x 30mm OD x 1.5mm Thk | JESD. 22 mm |
| 6. | 16586725 | [2] | BOLT,Hex, M8 x 1.25 x 40mm | TORM8 x 1.25 x 40 |
| 7. | 16673835 | [9] | BOLT,Hex, M8 x 30mm | TORM8 x 30 |
| 8. | 16586925 | [1] | BOLT,M8 x 50mm | TORM8 x 50 |
