纽荷兰零件查询(F5HFL413A A001) - ENGINE - 5801390423 - 84281067 (10.102.AK) - FRONT BLOCK ENGINE COVER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
497 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504379052 | [1] | COVER | TOR |
| 2. | 504379050 | [1] | GASKET | TOR |
| 3. | 84432127 | [2] | HEX SOC SCREW,M6 x 25mm, Cl 12.9 | ZED |
| 4. | 504382162 | [1] | BREATHER | TOR |
| 5. | 16586725 | [1] | BOLT,Hex, M8 x 1.25 x 40mm | TOR |
| 6. | 16592325 | [1] | BOLT,M8 x 60mm | AST |
| 7. | 16727724 | [3] | | STUD |
| 8. | 16673735 | [4] | BOLT,Hex, M8 x 1.25 x 25mm | TOR Superseded by part number: 10278301 |
| 9. | 16586625 | [14] | BOLT,M8 x 35mm | TOR |
| 10. | 4798844 | [3] | SCREW | FOR |
| 11. | 16586925 | [7] | BOLT,M8 x 50mm | TOR |
| 12. | 504379049 | [1] | COVER | TORIncl 13 - 16 |
| 13. | 99435557 | [2] | DOWEL,8.50mm Dia | TOR Superseded by part number: 2852481 |
| 14. | 504051236 | [1] | PLUG,Threaded, 1/8" | TOR |
| 15. | NSS | [1] | NOT SERVICED SEPARATELY | CONCover, Incl in12 |
| 16. | 504204989 | [1] | LUBE OIL NOZZLE | TOR |
| 17. | 16730924 | [3] | | STUD |
