凯斯零件查询(8480) - CASE IH FIXED CHAMBER ROUND BALER (1/90-12/00) (4-02) - ELECTRICAL ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
505 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700709702
|
[1] |
HARNESS
|
CAS
- wire, baler
|
| 2. |
7021728
|
[9] |
STRAP
|
CAS
TIE - cable Superseded by part number: 529070, 529070, NLS
|
| 3. |
700709723
|
[1] |
CONSOLE
|
HFI
BOX - control Superseded by part number: 700728181
|
| 4. |
700709703
|
[1] |
HARNESS
|
CAS
- control box
|
| 5. |
700709661
|
[1] |
ASSEMBLY
|
HFI
ACTUATOR
|
| 6. |
433-512
|
[3] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 7. |
231-5145
|
[5] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 8. |
432-816
|
[2] |
COTTER PIN,1/8" x 1"
|
CAS
1/8" x 1" Superseded by part number: 80755
|
| 9. |
495-21056
|
[11] |
WASHER,1/2"
|
CAS
1/2 HARDENED PLAIN WASHER Superseded by part number: 72187265, 80700
|
| 10. |
121-115
|
[2] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 11. |
700708090
|
[3] |
CLAMP
|
L
- line Superseded by part number: 86637978
|
| 12. |
700715140
|
[1] |
SWITCH
|
CAS
- normally closed
|
| 13. |
700120872
|
[1] |
PLATE
|
HFI
SUPPORT - switch
|
| 14. |
700715141
|
[1] |
COVER
|
CAS
- switch
|
| 15. |
340-1108
|
[2] |
SCREW,Cross Pan Hd, #10-24 x 1/2"
|
CAS
#10-24 X 1/2 CRPHMS
|
| 16. |
195-513
|
[2] |
WASHER,#10
|
CAS
PLAIN WASHER #10 Superseded by part number: 9824326
|
| 17. |
492-11010
|
[2] |
LOCK WASHER,#10
|
CAS
WASHER, LOCK, #10 Superseded by part number: 80684
|
| 18. |
225-14110
|
[2] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
