纽荷兰零件查询(F5HFL413A A001) - ENGINE - 5801390423 - 84281067 (10.103.AA) - CRANKSHAFT ASSEMBLY New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
307 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504387204 | [1] | CRANKSHAFT | TORIncl 2 - 7 Superseded by part number: 5801723073 |
| 2. | 500374310 | [3] | SCREW | TOR |
| 3. | 504381409 | [1] | GEAR | TOR |
| 4. | 504006981 | [1] | COTTER PIN | TOR |
| 5. | NSS | [1] | NOT SERVICED SEPARATELY | CONGear, Incl in 1 |
| 8. | 504014232 | [1] | SEAL | TOR |
| 9. | 504187305 | [1] | SHAFT SEAL | TOR |
| 10. | 8097862 | [1] | SET OF STD MAIN BRGS | TOR |
| 10. | 8097863 | [1] | SET OF MAIN BRGS -0.254,Main, -0.254 | TOR |
| 10. | 8097864 | [1] | SET OF MAIN BRGS -0.508 | TOR |
