纽荷兰零件查询(F5HFL413A A001) - ENGINE - 5801390423 - 84281067 (10.218.AF) - INJECTION EQUIPMENT - INJECTOR New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
781 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 5801470098 | [4] | FUEL SYSTEM INJECTOR | TORIncl 2, 3 |
| 1. | 5801470098R | [4] | REMAN-INJECT NOZZLE | TOR |
| 1. | 5801470098C | [4] | CORE-NOZZLE, INJECT | TORReturn Number |
| 2. | NSS | [4] | NOT SERVICED SEPARATELY | CONInjector, Incl in 1 |
| 3. | 4899689 | [4] | SEALING WASHER,7mm ID x 15mm OD x 1.5mm Thk | TOR |
| 4. | 504378841 | [4] | BRACKET | TOR |
| 5. | 5801473742 | [4] | STUD | TOR |
| 6. | 500353601 | [4] | WASHER | TOR |
| 7. | 17044731 | [4] | FLANGE NUT,Hex, M8 x 1.25, Cl 10 | LEC Superseded by part number: 17044735 |
