神钢零件查询(6D15-T) - MITSUBISHI DIESEL ENGINE - K909 II & K909LC II EXCAVATORS (1/87-12/06) (00-034) - OIL FILLER AND OIL LEVEL GAUGE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
262 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME940035 | [1] | GAGE, OIL GAUGE,OIL LEVEL | GAGE, OIL GAUGE,OIL LEVEL |
| . . | VAME064443 | [1] | DIPSTICK | KOBFOR SERVICE ONLY |
| 2. | VAME070578 | [1] | VALVE GUIDE | KOBGUIDE,OIL LEVEL |
| 5. | VAMH035230 | [2] | O-RING | KOBO-RING 10 |
| 6. | VAME070529 | [1] | STAY | KOBSTAY |
| 7. | VAMH021015 | [1] | CLAMP | KOBCLAMP Superseded by part number: 132398A1 |
| 8. | VAMF140205 | [1] | BOLT | KOBBOLT,FLANGE 6X16 |
| . . | VAMF434103 | [1] | NUT | KOBNUT,FLANGE 6 |
| 9. | VAMH000399 | [1] | SCREW | KOBBOLT 8X16 |
