| 1. |
100-11100
|
[1] |
SNAP RING,#100, Ext
|
CAS
Ring, Snap, #100, Ext Superseded by part number: 25121
|
| 2. |
700704663
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET - 50P, 20 tooth
|
| 3. |
52258
|
[1] |
BUSHING
|
CAS
1 X 14 GAUGE NRMB
|
| 4. |
433-828
|
[2] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 3/4", Gr 5
|
CAS
1/2-13 X 1-3/4 RHSNB Superseded by part number: 88530
|
| 5. |
80679
|
[2] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 6. |
425-108
|
[2] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 7. |
7870132
|
[1] |
BOLT,Sq Nk, 5/8" - 11 x 1 1/4", Gr 5
|
CAS
5/8-11 X 1-1/4 RHSNB
|
| 8. |
232-53110
|
[2] |
FLANGE NUT,Flg, 5/8"-11
|
CAS
5/8-11 HFTLN GR/G Superseded by part number: 84180923
|
| 9. |
413-1020
|
[1] |
BOLT,Hex, 5/8" - 11 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 280319
|
| 10. |
495-11066
|
[1] |
WASHER,5/8", SAE
|
CAS
5/8 NARROW PLAIN WASHER Superseded by part number: 87365
|
| 11. |
700110507
|
[1] |
ANGLE
|
HFI
|
| 12. |
95-81182
|
[8] |
WASHER,0.81" ID x 1.25" OD x 0.07" Thk
|
CAS
3/4 X 14 GAUGE NRMB
|
| 13. |
413-1288
|
[1] |
BOLT,Hex, 3/4" - 10 x 5-1/2", Gr 5
|
CAS
.75 X 5.5 UNC GR5 YZD Superseded by part number: 86507002
|
| 14. |
232-53112
|
[1] |
FLANGE NUT,Flg, 3/4"-10
|
CAS
3/4-10 HFTLN GR/G Superseded by part number: 86512372
|
| 15. |
7842693
|
[1] |
MOTOR, HYDRAULIC
|
HFI
MOTOR - hydraulic
|
| . . |
700709657
|
[1] |
MOTOR
|
CAS
- hydraulic Superseded by part number: 1986619C1
|
| 16. |
126-124
|
[1] |
WOODRUFF KEY,#15, 1/4" x 1", HT
|
CAS
Superseded by part number: 47471
|
| 17. |
825620C1
|
[4] |
RETAINER
|
IH
- bearing
|
| 18. |
700708091
|
[2] |
SPHERICAL BEARING,34.93 mm ID x 72 mm OD x 38.89 mm
|
CAS
BEARING - spherical Superseded by part number: 47577188, 47066
|
| 19. |
433-820
|
[7] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| 20. |
231-5348
|
[7] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 21. |
700709475
|
[1] |
MOTOR
|
CAS
- hydraulic
|
| 22. |
700121511
|
[1] |
SHIM
|
HFI
|
| 23. |
700120727
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET - 50P, 21 tooth
|
| 24. |
432-624
|
[1] |
COTTER PIN,3/32" x 1 1/2"
|
CAS
3/32" x 1 1/2"
|
| 25. |
700117339
|
[1] |
CAP
|
HFI
|
| 26. |
700117335
|
[1] |
SUPPORT
|
HFI
MOUNT - motor
|
| 27. |
434-616
|
[6] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 28. |
232-5316
|
[25] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 29. |
413-620
|
[1] |
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
|
CAS
C Hex, 3/8"-16 x 1 1/4", G5, Full Thd Superseded by part number: 72187207, 88011
|
| 30. |
496-11041
|
[3] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 31. |
700117340
|
[1] |
SHIELD
|
HFI
- drive
|
| 32. |
413-616
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 33. |
700118625
|
[1] |
STRAP
|
HFI
- indicator
|
| 34. |
700108883
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET AND DRIVE HUB
|
| 35. |
700704331
|
[8] |
LINK
|
HFI
- roller, 100 R/C, 1" pitch
|
| 36. |
700704513
|
[16] |
HEX SOC SCREW,Flat Hd, 3/8"-16 x 1 7/8"
|
CAS
3/8-16 X 1 HSFCHCS
|
| 37. |
700109889
|
[1] |
SUPPORT
|
HFI
CAP
|
| 38. |
1791D
|
[1] |
CHAIN (AG),#50, 192 Links x 15.88mm = 3048mm
|
IH
CHAIN - roller, #50 (10 foot bulk)
|
| 39. |
47530
|
[1] |
LINK, CONNECTING
|
IH
LINK - connector, 50 R/C
|
| 40. |
700117342
|
[1] |
SHIELD
|
HFI
- drive
|
