纽荷兰零件查询(F5HFL413B A002) - ENGINE 5801438206 - 84393712 (10.101.03) - ENGINE BREATHERS (504381675) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
609 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 5801514511 | [1] | BREATHER | TORASSY Contains Ref.2, 3, 9 Superseded by part number: 5801542914 |
| 2. | 504325903 | [1] | O-RING,91.41mm ID x 3.47mm | TOR |
| 3. | 504050244 | [1] | SHAFT SEAL | TOR |
| 4. | 16867073 | [1] | SNAP RING | TOR |
| 5. | 504075145 | [1] | ELEMENT | TOR |
| 6. | 2852197 | [3] | FLANGE NUT,M6 x 1 | TOR Superseded by part number: 17044625 |
| 7. | 5801363192 | [1] | BUSHING | TOR |
| 8. | 5801363191 | [1] | SHAFT | TOR |
| 9. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
