纽荷兰零件查询(F5HFL413B A002) - ENGINE 5801438206 - 84393712 (10.106.01) - CAMSHAFT - TIMING CONTROL (5801361387) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
551 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 5801390145 | [1] | CAMSHAFT | TORASSY |
| 2. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 3. | 504345384 | [1] | PIN | TOR |
| 4. | 504387776 | [8] | TAPPET | TOR |
| 5. | 504387516 | [8] | PUSH ROD | TOR |
| 6. | 4897457 | [1] | SUPPORT | TOR |
| 7. | 2854311 | [2] | SCREW | TOR |
| 8. | 5801391944 | [1] | GEAR | TORASSY |
| 10. | 10839510 | [2] | DOWEL,M6 x 9 | TTF Superseded by part number: 17275310 |
| 11. | 16673735 | [6] | BOLT,Hex, M8 x 1.25 x 25mm | TOR Superseded by part number: 10278301 |
| 12. | 504389542 | [1] | WHEEL DISC | TOR |
| 13. | 5801363682 | [1] | GEAR | TOR |
| 14. | 504361502 | [1] | PIN | TOR |
| 15. | 16678034 | [1] | BOLT,Hex, M12 x 40mm | TOR |
